Deep groove, or single row , ball bearings are the most frequently used bearings. They use an uninterrupted raceway which makes them ideal for radial loads .This design enables precision endurance, even in high-speed performance.

Deep groove ball bearings are the most frequently used posture kind and therefore are especially versatile. They adapt radial and axial loads in both directions, are simple to mount, and need less maintenance compared to other bearing types.

The heavy groove ball bearing catalog lists a huge selection of designs, variations and dimensions of deep groove ball bearings. Beyond our catalog supplying, the SKF Explorer deep groove ball bearings are customizable to provide benefits for applications using particular performance requirements.

Deep groove ball bearings are most widly used. They can be used for gearboxes, motors, household appliances, internal combustion engines, automobile, etc. We can provide deep groove ball bearings of Z1V1, Z2V2, Z3V3 such levels.

Showing 1–12 of 188 results

Show sidebar
10BSW02 bearing
Close

10BSW02 Bearing 10*30*8mm Imperial Ball Bearing 10bsw02

Dimensions: 10*30*8mm Mass:0.1kg/pc Material: Gcr15 steel Lubrication: Standard grease Closure: Metal seal on both sides Cross Interchange: 10BSW02, 10bsw02,  10*30*8, 10-30-8, 10x30x8 etc
10T6309J30 bearing
Close

10T6309J30 Bearing 10T 6309 J30 Flange Ball Bearing 45*100*25

Inner Diameter: 45mm Outer Diameter: 100mm Flange Diameter: 108mm Width: 25mm Mass: 0.85kg Material: Gcr15 chrome steel J30: C3 clearance, larger than C0 External Modification: F - Flange
13BX4213 bearing
Close

13BX4213 Bearing 13x42x13 Ball Bearing For Automobile Gearbox

Inner Diameter: 13mm Outer Diameter: 42mm Width: 13mm Weight: 0.1kg Material: chrome steel Number of Row: single row Application: automobile gearbox, etc.
16015M bearing
Close

16015M Bearing 16015M-C3 Brass Cage Ball Bearing 75*115*13

Mass: 0.45kg/pc Size: 75*115*13mm Material: Gcr15 steel M: Solid brass cage C3: Internal clearance is larger than normal Structure: Single row deep groove ball bearing Also Known As: 16015M, 16015 M, 16015M-C3, 16015M/C3, 16015 M-C3, 16015.M.C3 and so on.
Close

16020 Ball Bearings 16020-2rs Precision Radial Deep Groove Bearing

Dimensions: 100*150*16mm Weight:0.93kg/piece Material: Chrome steel Cage: Standard steel cage Lubrication: Grease or oil Limiting Speed: 5000 rpm Certificate: ISO9001: 2015 Operating Temperature: -20°C to 120°C
16034 bearing
Close

16034 Bearing 16034 C3 Radial Deep Groove Ball Bearings 170*260*28

Inner diameter: 170mm Outer diameter: 260mm Width: 28mm Weight: 4.9kg Cage: steel cage Material:52100 chrome steel Bore: cylindrical bore Number of row: single row Seal type: open without seal
Close

16034 Bearing 170x260x28 Open Type Deep Groove Ball Bearing

Inside diameter: 170mm Outside diameter: 260mm Width: 28mm Mass: 4.9kg/piece Reference speed: 5300 r/min Limiting speed: 3200 r/min Material: chrome steel Cage: standard steel cage
1635zz bearing
Close

1635zz Bearing 1635 Ball Bearing 19.05*44.45*12.7

Inside Diameter: 19.05mm = 0.75 inch Outside Diameter: 44.45mm = 1.75 inch Width: 12.70mm = 0.5 inch Number of Row: Single row Brand: TOPE or OEM Certificate: ISO9001:2015 MOQ: 10PCS for 1635 bearing
173110-2RS bearing
Close

173110-2RS Bearing MR077 Radial Ball Bearings 17x31x10mm

Inner diameter: 17mm Outer diameter: 31mm Thickness: 10mm Weight: 0.036kg/pc Lubrication: grease or oil Structure: single row deep groove ball bearing Alternative Numbers: 173110-2RS, 173110 2RS, MR173110, MR077, 173110RS, 173110
205KRR2-SSM6-NR bearing
Close

205KRR2-SSM6-NR Bearing 205KRR2SSM6NR Hex Bore Ball Bearings

Bore Diameter: 0.8750 in Outside Diameter: 52 mm Overall Width: 27.94 mm Weight: 0.2kg Bore Type: Hex Material: SAE 52100 Steel Seal: Rubber seal on both sides NP: Bearing with snap ring and snap ring groove
3TM-6213NR bearing
Close

3TM-6213NR Bearing 6213-NR Radial Ball Bearing With Snap Ring

d: 65mm B: 23mm Weight: 1kg C: 58.5 kN C0: 40.5 kN Precision: P0/ABEC1 HS Code: 8482102000 Radial Interal Play: C0/CN NR: Bearing has snap ring groove and snap ring on outer ring
4213ATN9 bearing
Close

4213ATN9 Bearing 4213-B-TVH Double Row Ball Bearing 65*120*31

ID: 65mm OD: 120mm Width: 31mm Mass: 1.6kg/pc ATN9: Nylon cage Structure: Double row deep groove ball bearing Cross Reference: 4213ATN9, 4213 ATN9, 4213-B-TVH, 4213B.TVH
