Angular contact ball bearings belongs to high precision ball bearings, which revolving speed is very high. They are mainly used for machine tool spindle, high speed motor, gas turbine, centrifugal separator, automobile front wheel, drilling platform, etc. Angular contact ball bearings contains single row, double row and four point angular contact ball bearings.

Angular contact ball bearings have inner and outer ring raceways which are displaced relative to one another at the direction of the bearing axis. This usually means that these claws are made to accommodate combined heaps, i.e. concurrently behaving radial and axial loads.

The axial load carrying capability of angular contact ball bearings increases since the contact angle increases. The contact angle is defined as the angle between the line connecting the points of contact of the ball along with the raceways from the radial plane, and the joint load is sent from 1 raceway to the other, and also a line perpendicular to the bearing axis

Showing 1–12 of 74 results

Show sidebar
17TAC47BSUC10PNB bearing
Close

17TAC47BSUC10PN7B Bearing 17TAC47B Ball Screw Support Bearing 17x47x15mm

Size: 17x47x15mm Mass: 0.21kg B: High Capacity & Higher Speed (Replaces “A” Type) SU: Single Universal C10: Metric Series PN7B: Bore And O.D. Tolerance Is Tighter; Used With SU Combination. Category: Angular Contact Thrust Ball Bearings
20TAC47BDTPN7A bearing
Close

20TAC47BDTPN7A Bearing 20TAC47B DTPN7A Ball Screw Support Bearing

Inner (d) MM: 20,00 Outer (D) MM: 47,00 Width (B) MM: 30,00 Weight (kg): 0.27 Cage Type: P - Plastic Molded Cage Precision: P4 Precision (Higher than P5) Contact Angle: 40 Degrees
234420M-SP bearing
Close

234420-M-SP Bearing 234420M.SP Axial Angular Contact Ball Bearings

ID: 100mm OD: 150mm Width: 60mm Mass: 3.18kg/pc M: Solid brass cage, ball guided SP: Super precision, higher than P4S Cross Reference: 234420-M-SP, 234420M.SP and so on
25TAC62CSUHPN7C bearing
Close

25TAC62CSUHPN7C Bearing 25TAC62C Ball Screw Bearing 25x62x15

ID: 25mm OD: 62mm Width: 15mm Weight: 0.252kg/pc Precision: P2, ABEC9 Cage: Steel/Standard Cage Brand: NSK or FAG or others
30TAC62B ball screw support bearing
Close

30TAC62B Ball Screw Support Bearing 30TAC62BSUC10PN7B 30*62*15

Inner (d) MM: 30 Outer (D) MM: 62 Width (B) MM: 15 Mass: 0.212kg/pc Manufacture: NSK Precision: P4, higher than P5 Interchange: 30TAC62B,30TAC62BSUC10PN7B, 30TAC62B SUC10PN7B
30TAC62CSUHPN7C bearing
Close

30TAC62CSUHPN7C Bearing 30TAC62C Ball Screw Support Bearing

Interchange: 30TAC62CSUHPN7C, 30TAC62C, 30TAC62C SUHPN7C Inner (d) MM: 30 Outer (D) MM: 62 Width (B) MM: 15 Mass: 0.212kg Cage Type P: Plastic Molded Cage Precision: 7C, equal to P2
3204 A-2Z bearing
Close

3204 A-2Z Double Row Bearing 3204 ZZ Angular Contact Ball Bearing 5204zz 20*47*20.6mm

Model Number: 3204 A-2Z, 3204 2z, 3204B-2ZR-TVH, 3204ZZ, 5204ZZ Dimensions: 20x 47x 20.6mm/Metric Weight: 0.18kg/pc Basic Dynamic Load Rating Cr: 20 kN Basic Static Load Rating Cor: 12 kN Grease Lubrication: 14000
3207 bearing
Close

3207 Bearing 3207-2RS Sealed Angular Contact Ball Bearing 3207-ZZ

Inner (d): 35mm Outer (D): 72mm Width (B): 27mm Seal ZZ/2Z: Steel Seal on Two Sides Cage Type: Steel or Standard Cage External Modification:No External Modification Category: Double Row Angular Contact Ball Bearing
3210ZZ bearing
Close

3210ZZ Bearing 3210-ZZ Double Row Angular Contact Bearing

ID: 50mm OD: 90mm Width: 30.2mm Weight: 0.735kg/pc Cage: Standard steel cage Seal: Steel seal on both sides Cross Reference: 3210ZZ, 3210-ZZ, 3210-2Z, 3210 2Z, 3210 zz
3218A/C3 bearing
Close

3218 A/C3 Bearing 3218 A Angular Contact Ball Bearing 90*160*52.4

Model Number: 3218 A/C3, 3218A, 3218 AC3, 5218 AC3, Bore Diameter: 90 mm Outside Diameter: 160 mm Outer Ring Width: 52.4 mm Weight: 4.14kg/pc Contact Angle: 30 ° Category: angular contact ball bearing
3310A/C3 bearing
Close

3310A/C3 Bearing 3310 A/C3 Double Row Angular Contact Ball Bearing

ID: 50mm OD: 110mm Width: 44.4mm Mass: 1.71kg/pc Cage: Steel cage Material: Chrome steel Cross Reference: 3310A/C3, 3310 A/C3, 3310A, 3310 A
3318BM bearing
Close

3318BM Bearing 40° Contact Angle 3318 Angular Contact Ball Bearing

Model Number: 3318BM, 3318 Dimensions: 90*190*73mm Mass: 9.23kg/pcs Structure: Angular Contact Ball Bearing Material: Chrome Steel, Gcr15 B: 40° Contact Angle M: Solid Brass Cage and Ball-Guided
