Sealed Ball Bearing Archives

173110-2RS Bearing MR077 Radial Ball Bearings 17x31x10mm

Inner diameter: 17mm Outer diameter: 31mm Thickness: 10mm Weight: 0.036kg/pc Lubrication: grease or oil Structure: single row deep groove ball bearing Alternative Numbers: 173110-2RS, 173110 2RS, MR173110, MR077, 173110RS, 173110

6006.2RS.C3 Bearing 6006-2RS-C3 Radial Ball Bearing 30x55x13

Bore Diameter: 30 mm Outer Diameter: 55 mm Thickness: 13 mm Weight: 0.112kg Material: Gcr15/ 52100 steel Internal Play: C3, larger than C0 Working Temperature: -30°C to 120°C

Hot

6203-2RSH Bearing 6203-2RS1 Sealed Ball Bearing 17x40x12mm

Inner Diameter: 17mm Outer Diameter: 40mm Width: 12mm Weight: 0.065kg Bore: Cylindrical bore Cage: Standard steel cage Number of Row: Single row Precision: Standard ABEC1/P0

6203-2Z Bearing 6203 2Z Double Shielded Ball Bearings 17 x 40 x 12

Size: 17*40*12 Weight: 0.065kg Materail: Gcr15 steel Bore: Cylindrical bore Cage: Standard steel cage Number of Row: Single row Precision: Standard ABEC1/P0 Radial Internal Play: Standard C0

6209-2RS-C3 Bearing 6209.2RS.C3 Shielded Ball Bearing 45-85-19

ID: 45mm OD: 85mm B: 19mm Weight: 0.42kg Cage: Steel cage Material: SAE52100/100Cr6/Gcr15 steel Lubrication: Standard grease or oil Radial Internal Paly: C3 (lager than C0)

6209zz Bearing 6209-2z Single Row Ball Bearing 45x85x19

Dimensions: 45x85x19mm Weight: 0.42kg/pc HS Code: 8482102000 Material: SAE52100/100Cr6 Lubrication: Standard grease or oil Radial Paly: C0 or C3(lager than C0) Working Temperature: -30°C to 120°C

6301/15 2RS Bearing 6301-15 2rs Deep Groove Ball Bearing 15x37x12

Inner Diameter: 15mm Outer Diameter: 37mm Width: 12mm Weight: 0.053kg HS Code: 8482102000 Material: chrome steel GCr15 Precision: standard P0 or ABEC1

6306-2RS-C3 Bearing C3 Clearance Ball Bearing 6306.2RS.C3 30X72X19

Dimensions: 30X72X19mm Weight: 0.35kg/piece HS Code: 8482102000 Material: chrome steel Number of Row: single row Structure: deep groove ball bearing Seal: rubber seal on both sides Internal Play: C3, larger than C0

6306/31.75-2RS Bearing 6306/31.75 Imperial Ball Bearing 31.75X72X19

ID: 31.75mm OD: 72mm B: 19mm Weight: 0.34kg Material: chrome steel Number of Row: single row Precision: ABEC1/P0 Lubrication: grease or oil

6307-2Z Ball Bearing 6307-2Z/C3 Radial Bearings 35x80x21

d：35 mm D：80 mm B：21 mm Weight: 0.48kg/piece Limiting Speed: 9500 r/min Material: 52100 steel/Gcr15 steel Cage Material: steel cage Lubrication: standard grease

6314-2RS1 Bearing 6314.2RS Double Shielded Ball Bearings 7015035

Size: 70*150*35mm Weight: 2.6kg Cage: steel cage Material: 52100 steel Internal Play: C0 or C3 available Closure: rubber seal on both sides Dynamic Load Rating (KN):111 Static Load Rating (KN):68

6316-2Z/C3VL0241 Insulated Bearing 6316-2Z/C3 VL0241 Insocoat Bearing

Bore Diameter: 80 mm Outside Diameter: 170 mm Overall Width: 39 mm Weight: 3.7kg/pc Internal Play: C3 Outer Ring Coating: electrically insulated VL0241: External surfaces of the outer ring coated with aluminium oxide, which can withstand voltages up to 1.000 V DC
