RLS 24 Bearing LS 19 Imperial Ball Bearing 76.2X146.05X26.988
Inner Diameter: 3 inch/ 76.200mm
Outer Diameter: 5.75 inch/ 146.050mm
Width: 1.0625 inch/ 26.988mm
Mass: 4.171lb/ 1.892kg
Sheilds: without
Bore: cylindrical bore
Warranty: 1 year
Certificate: ISO9001: 2015
RLS 24 Bearing Product Specifications:
RLS 24 bearing comes from the inch-series deep groove ball bearing range.
Concerning this bearing model number,
Inner Diameter: 3 inch/ 76.200mm
Outer Diameter: 5.75 inch/ 146.050mm
Width: 1.0625 inch/ 26.988mm
Mass: 4.171lb/ 1.892kg
Sheilds: without
Bore: cylindrical bore
Material: bearing steel
Internal Play: standard C0 or CN
Lubrication: standard grease or oil
Working Temperature: -30 °C to 120 °C
Replacements: RLS24, RLS-24, LS 19, LS19, LJ3″, LJ 3 E, LJ 3, LJ3
Key Advantages:
Durable Performance – RLS-24 bearings are manufactured with premium-grade materials to withstand heavy loads, harsh environments, and long operating hours.
Low Friction & High Efficiency – RLS 24 bearing is designed to minimize friction and heat build-up, ensuring smoother rotation, reduced wear, and improved energy efficiency.
Versatile Applications – Widely used in industrial machinery, automotive systems, agricultural equipment, and other demanding engineering applications.
Precision & Stability – Bearing LJ 3 E ensures accurate alignment and stable operation at high speeds, while reducing vibration and noise.
Easy Maintenance – Simple to lubricate and inspect, helping reduce downtime and extend overall service life.
RLS Series Bearings Equivalent Reference:
| RLS 4 | LS 5 | LJ 1/2 | RLS 4 |
| RLS 5 | LS 7 | LJ 5/8 | RLS 5 |
| RLS 6 | LS 8 | LJ 3/4 | RLS 6 |
| RLS 7 | LS 9 | LJ 7/8 | RLS 7 |
| RLS 8 | LS 10 | LJ 1 E | RLS 8 |
| RLS 9 | LS 11 | LJ 1 1/8 | RLS 9 |
| RLS 10 | LS 12 | LJ 1 1/4 | RLS 10 |
| RLS 11 | LS 12 1/2 | LJ 1 3/8 | RLS 11 |
| RLS 12 | LS 13 | LJ 1 1/2 | RLS 12 |
| RLS 13 | LS 13 1/2 | LJ 1 5/8 | RLS 13 |
| RLS 14 | LS 14 | LJ 1 3/4 | RLS 14 |
| RLS 15 | LS 14 1/2 | LJ 1 7/8 | RLS 15 |
| RLS 16 | LS 15 | LJ 2 E | RLS 16 |
| RLS 18 | LS 16 | LJ 2 1/4 | RLS 18 |
| RLS 20 | LS 17 | LJ 2 1/2 | RLS 20 |
| RLS 22 | LS 18 | LJ 2 3/4 | RLS 22 |
| RLS 24 | LS 19 | LJ 3 E | RLS 24 |
| RLS 26 | LS 19 1/2 | LJ 3 1/4 | RLS 26 |
| RLS 28 | LS 20 | LJ 3 1/2 | RLS 28 |
Questions that help when 2X146 and 05X26 is on the shortlist
When is 2X146 and 05X26 worth comparing against nearby deep groove ball bearings options?
Comparison helps when dimensional fit is only part of the decision and load direction, sealing, clearance, speed, temperature, or repeat-order stability still need to be confirmed. Reviewing one or two nearby options early usually reduces sourcing mistakes later.
What details usually matter before approving 2X146 and 05X26 for repeat supply?
Buyers normally confirm the part reference, main dimensions, application, speed range, operating environment, sealing needs, and any packaging or marking requirements. That gives the supplier a cleaner basis for confirming availability and suitable alternatives.
Which next step usually helps after 2X146 and 05X26 is shortlisted?
A quick review of Deep Groove Ball Bearings, one more commercial destination, and one practical guide usually saves time. That combination helps separate simple replacement orders from jobs that still need fit or application review.
Why keep a supporting guide linked beside 2X146 and 05X26?
Because it makes later decisions faster. When sizing notes, application cues, and nearby options stay close to the product, engineering, purchasing, and maintenance teams can revisit the same logic without starting the review from zero.
Shipping Method:
1. Sea shipping for mass cargos (GW > 500KGS)
2. Air shipping (GW between 100KGS – 500 KGS)
3. Express, such as DHL, TNT, Fedex, UPS for small cargos ( GW < 100KGS)
4. If you have shipping agent in China, we can send goods to your shipping agent's warehouse
Payment Terms:
We accept T/T, W/U, PAYPAL, L/C etc
Buyer FAQ
Questions buyers ask before choosing the next bearing option
What should I confirm before ordering RLS 24 Bearing LS 19 Imperial Ball Bearing 76.2X146.05X26.988?
Confirm the bearing number, bore size, outside diameter, width, seal or shield type, cage material, clearance, precision level, quantity, and application. These details help prevent a size match from becoming a performance mismatch.
Can this bearing be matched for replacement or repeat supply?
Yes. Replacement and repeat orders are easier when the original marking, measured dimensions, photos, application, and quantity are available. If the marking is unclear, the team can start from the size and working condition.
Which product family does this bearing belong to?
This item is handled within the Deep Groove Ball Bearings family. Comparing the family page can help buyers review similar sizes, seal options, load direction, and related bearing choices before requesting a quote.
What affects price and lead time for this bearing?
Price and lead time can change with quantity, stock availability, precision grade, clearance, material, cage, seal or shield type, lubrication, packaging, and whether the order needs standard matching or custom production.
How is this bearing checked before delivery?
Inspection can include material review, dimensional measurement, noise and vibration checks, surface and crack checks, visual review, and packaging inspection according to the confirmed order requirements.
Need help checking fit, price, or lead time? Request a bearing quote
