1206ETN9 Bearing 1206 ETN9 Self Aligning Ball Bearing 30*62*16
Inner (d) MM: 30
Outer (D) MM: 62
Width (B) MM: 16
Mass: 0.226kg/pc
Category: Self Aligning Ball Bearing Double Row
TN9: Injection Moulded Snap-Type Cage Of Glass Fibre Reinforced Polyamide 6,6, Ball Centered.
1207K Bearing 1207 Self Aligning Ball Bearing 35*72*17
Inside Diameter: 35mm
Outside Diameter: 72mm
Width: 17mm
Dimensions: 35x72x17 (mm)
Weight: 0.317kg
Precision: ABEC1, P0
Clearance: CN or C0
Material: Chrome steel, Gcr15
Limiting Speed (r/min): 13,000
1208K Bearing 1208 Tapered Self Aliging Ball Bearing 1208K.C3
Inner (d): 40mm
Outer (D): 80mm
Width (B): 18mm
Weight (kg): 0.418
Material: Chrome steel
K: Tapered bore, taper 1:12
Clearance: Standard C0 or C3 (lager than C0)
1209 Bearing 1209K Self Aligning Ball Bearing 45*85*19
Inner (d): 45mm
Outer (D): 85mm
Width (B): 19mm
Mass: 0.46kg/pc
Structure: Self Aligning Ball Bearing
Number of Row: Double Row
Material: Chrome Steel Gcr15
1210TV Bearing 1210 ETN9 Self Aligning Ball Bearing 1210TVH
Inner (d): 50mm
Outer (D): 90mm
Width (B): 20mm
Mass: 0.525kg/pc
Materal: Chrome Steel
Cage Type: Nylon Cage
Radial Internal Play: CN/C0 Play
1212 ETN9 Bearing 1212TV Nylon Cage Self Aligning Ball Bearing 1212TVH
Size: 60*110*22mm
Mass: 0.9kg/pc
Cage: Nylon cage
Material: Chrome steel, Gcr15
Certificate: ISO9001: 2015
Structure: Self aligning ball bearing
Interchange:1212 ETN9, 1212TV, 1212TVH, 1212ETN9
3207 Bearing 3207-2RS Sealed Angular Contact Ball Bearing 3207-ZZ
Inner (d): 35mm
Outer (D): 72mm
Width (B): 27mm
Seal ZZ/2Z: Steel Seal on Two Sides
Cage Type: Steel or Standard Cage
External Modification:No External Modification
Category: Double Row Angular Contact Ball Bearing
3210ZZ Bearing 3210-ZZ Double Row Angular Contact Bearing
ID: 50mm
OD: 90mm
Width: 30.2mm
Weight: 0.735kg/pc
Cage: Standard steel cage
Seal: Steel seal on both sides
Cross Reference: 3210ZZ, 3210-ZZ, 3210-2Z, 3210 2Z, 3210 zz
3218 A/C3 Bearing 3218 A Angular Contact Ball Bearing 90*160*52.4
Model Number: 3218 A/C3, 3218A, 3218 AC3, 5218 AC3,
Bore Diameter: 90 mm
Outside Diameter: 160 mm
Outer Ring Width: 52.4 mm
Weight: 4.14kg/pc
Contact Angle: 30 °
Category: angular contact ball bearing
3318BM Bearing 40° Contact Angle 3318 Angular Contact Ball Bearing
Model Number: 3318BM, 3318
Dimensions: 90*190*73mm
Mass: 9.23kg/pcs
Structure: Angular Contact Ball Bearing
Material: Chrome Steel, Gcr15
B: 40° Contact Angle
M: Solid Brass Cage and Ball-Guided
35TAC72B Bearing 35TAC72BSUC10PN7B Spindle Bearings 35*72*15
Mass: 0.31kg/pc
Dimensions: 35*72*15mm
Cage: Standard steel cage
B: High capacity & higher speed
SU: Single universal
C10: Metric series
PN7B: Bore And O.D. tolerance is tighter
3814-B-2RS-TVH Bearing 3814-2RS Double Row Ball Bearing 70*90*15
Mass: 0.205kg
Size: 70*90*15mm
Contact angle: α = 25°
Limiting speed: 3400rpm
TVH: Glass fiber reinforced nylon solid cage
Structure: Angular contact ball bearing, double row
Cross Reference: 3814-B-2RS-TVH, 3814-2RS, 3814 2RS
