Inner Diameter (d): 6mm
Outer Diameter (D): 17mm
Width (B): 6mm
Mass: 0.012kg
Shields: without
A: 30° contact angle
TYN: polyamide resin cage
DFL: set of 2 bearings, face-to-face
Bore (d): 6mm
Outer Diameter (D): 17mm
Width (B): 6mm
Mass: 0.012kg
Shields: without
Material: chrome steel
Preload: light preload
Max Revolving Speed: 7500RPM
ABEC Rating: ABEC 5
A: 30° contact angle
TYN: polyamide resin cage
DFL: set of 2 bearings, face-to-face
P5: dimensional and running accuracy to ISO tolerance class 5
Lubrication: grease or oil
Category: angular contact ball bearing
1. 706ATYNDFLP5 angular contact ball bearing with high-precision angular contact design
2. P5 precision grade for accurate and stable rotation
3. Polyamide resin cage for low friction and smooth running
4. Suitable for high-speed machine tool applications
5. Supports combined radial and axial loads
