Inner Diameter: 85 mm
Outer Diameter: 150 mm
Width: 28 mm
Weight: 1.98kg
Seal: without
Material: 52100 steel
Hardness: 58-64 HRC
Contact Angle: 40 °
Inner Diameter: 85 mm
Outer Diameter: 150 mm
Width: 28 mm
Weight: 1.98kg
Seal: without
Material: 52100 steel
Hardness: 58-64 HRC
Contact Angle: 40 °
Relubricate Features: without
Lubrication: grease or oil
Tolerance Class: P6, ABEC 3
Number of Row: single
Structure: angular contact ball bearing
Suffix “BE”: bearing with optimized internal construction and a 40° contact angle
Suffix “CB”: bearing suitable for universal matching
Suffix “M”: machined window-type brass cage
Due to the wide variety of bearing models available, we are unable to list every model on our website.
If you cannot find the bearing model you need, please send us the model number, quantity, and preferred brand if applicable. Our team will check availability and provide you with a quotation as soon as possible.
