47679-47620 Bearing 47679/47620 Inch Taper Roller Bearing SET426
Cup Number: 47620
Cone Number: 47679
Inner (d): 76.2 mm/ 3.000 in
Outer (D): 133.350 mm/ 5.250 in
Width (T): 33.338 mm/ 1.3125 in
Mass: 1.90kg/ 4.189lb
Warranty: 1 year
Shields: open without
47679-47620 Bearing Specification:
47679-47620 bearing is a combination of a cup and a cone.
Cup Number: 47620
Cone Number: 47679
Inner (d): 76.2 mm/ 3.000 in
Outer (D): 133.350 mm/ 5.250 in
Width (T): 33.338 mm/ 1.3125 in
Mass: 1.90kg/ 4.189lb
Warranty: 1 year
Shields: open without
Cage Material: pressed steel
Precision: standard precision ABEC1, P0
Structure: tapered roller bearing, single row
Also kKnown As: 47679 – 47620,47679 / 47620,47679/20, 47679/620, Set426, SET 426, 47679-99401, SET426-900SA, 4T-47679/47620
SET426 Bearing Applications:
Automotive Axles and Wheel Hubs: 47679 – 47620 bearings are widely used in trucks, trailers, and heavy-duty vehicles for wheel bearing assemblies.
Industrial Gearboxes: Ideal for supporting shafts and handling combined loads in heavy machinery.
Agricultural Equipment: Utilized in tractors, harvesters, and other farm machinery for reliable load support.
Construction Machinery: Applied in excavators, loaders, and cranes for robust performance under demanding conditions.
SET Number & Bearing Model Cross-Reference Guide:
| SET Number | SET COMPONENTS |
| SET1 | LM11749/LM11710 |
| SET2 | LM11949/LM11910 |
| SET3 | M12649/M12610 |
| SET4 | L44649/L44610 |
| SET5 | LM48548/LM48510 |
| SET6 | LM67048/LM67010 |
| SET8 | L45449/L45410 |
| SET10 | U399/K426898 |
| SET11 | JL69349/JL69310 |
| SET12 | LM12749/LM12710 |
| SET13 | L68149/L68110 |
| SET14 | L44643/L44610 |
| SET15 | 07100/07196 |
| SET16 | LM12749/LM12711 |
| SET18 | LM102949/LM102911 |
| SET20 | U399A/K518783/K523967 |
| SET268 | LM29749/LM29711 |
| SET280 | U298/K529698 |
| SET284 | U298/K525376 |
| SET308 | M84548/M84510 |
| SET309 | M86649/M86610 |
| SET312 | HM89449/HM89410 |
| SET328 | M802048/M802011 |
| SET401 | 580/572 |
| SET402 | 582/572 |
| SET403 | 594A/592A |
| SET404 | 598A/592A |
| SET405 | 663/653 |
| SET406 | 3782/3720 |
| SET407 | 28622/28682 |
| SET408 | 39590/39520 |
| SET409 | 45220/45280 |
| SET410 | 45220/45284 |
| SET411 | 47686/47620 |
| SET412 | HM212047/HM212011 |
| SET413 | HM212049/HM212011 |
| SET414 | HM218248/HM218210 |
| SET415 | HM518445/HM518410 |
| SET416 | 45291/45220 |
| SET417 | 47890/47820 |
| SET418 | H715311/H715334 |
| SET419 | H715311/H715343 |
| SET420 | H715311/H715345 |
| SET421 | HM516410/HM516449A |
| SET422 | HM516410/HM516449C |
| SET423 | 6420/6461A |
| SET424 | 552A/555S |
| SET425 | 563/567 |
| SET426 | 47620/47679 |
Installation Tips for 47679-47620 Bearing:
1. Inspect Components:
Before installation, check the bearing, housing, and shaft for any signs of wear, damage, or contamination. Clean all components thoroughly.
2. Correct Orientation:
Ensure the cup (47620) and cone (47679 with rollers and cage) are installed in the correct orientation and properly aligned.
3. Use Proper Tools:
Use bearing installation tools or a press to avoid applying force directly to the rollers or raceways, which can cause damage.
4. Lubrication:
Apply the recommended type and amount of lubricant (grease or oil) to the bearing before installation. Proper lubrication is essential for performance and longevity.
5. Seating the Bearing:
Press the cone onto the shaft and the cup into the housing evenly and squarely to prevent misalignment. Do not strike the bearing with a hammer.
6. Preload/Endplay Adjustment:
Adjust the bearing preload or endplay according to the manufacturer’s specifications. Too much preload can cause overheating, while excessive endplay can lead to premature failure.
Questions that help when 47679-47620 and 47679/47620 is on the shortlist
When is 47679-47620 and 47679/47620 worth comparing against nearby taper roller bearings options?
Comparison helps when dimensional fit is only part of the decision and load direction, sealing, clearance, speed, temperature, or repeat-order stability still need to be confirmed. Reviewing one or two nearby options early usually reduces sourcing mistakes later.
What details usually matter before approving 47679-47620 and 47679/47620 for repeat supply?
Buyers normally confirm the part reference, main dimensions, application, speed range, operating environment, sealing needs, and any packaging or marking requirements. That gives the supplier a cleaner basis for confirming availability and suitable alternatives.
Which next step usually helps after 47679-47620 and 47679/47620 is shortlisted?
A quick review of Taper Roller Bearings, one more commercial destination, and one practical guide usually saves time. That combination helps separate simple replacement orders from jobs that still need fit or application review.
Why keep a supporting guide linked beside 47679-47620 and 47679/47620?
Because it makes later decisions faster. When sizing notes, application cues, and nearby options stay close to the product, engineering, purchasing, and maintenance teams can revisit the same logic without starting the review from zero.
Shipping Method:
1. Sea shipping for mass cargos (GW > 500KGS)
2. Air shipping (GW between 100KGS – 500 KGS)
3. Express, such as DHL, TNT, Fedex, UPS for small cargos ( GW < 100KGS)
4. If you have shipping agent in China, we can send goods to your shipping agent's warehouse
Payment Terms:
We accept T/T, W/U, PAYPAL, L/C etc
Buyer FAQ
Questions buyers ask before choosing the next bearing option
What should I confirm before ordering 47679-47620 Bearing 47679/47620 Inch Taper Roller Bearing SET426?
Confirm the bearing number, bore size, outside diameter, width, seal or shield type, cage material, clearance, precision level, quantity, and application. These details help prevent a size match from becoming a performance mismatch.
Can this bearing be matched for replacement or repeat supply?
Yes. Replacement and repeat orders are easier when the original marking, measured dimensions, photos, application, and quantity are available. If the marking is unclear, the team can start from the size and working condition.
Which product family does this bearing belong to?
This item is handled within the Taper Roller Bearings family. Comparing the family page can help buyers review similar sizes, seal options, load direction, and related bearing choices before requesting a quote.
What affects price and lead time for this bearing?
Price and lead time can change with quantity, stock availability, precision grade, clearance, material, cage, seal or shield type, lubrication, packaging, and whether the order needs standard matching or custom production.
How is this bearing checked before delivery?
Inspection can include material review, dimensional measurement, noise and vibration checks, surface and crack checks, visual review, and packaging inspection according to the confirmed order requirements.
Need help checking fit, price, or lead time? Request a bearing quote
