838/832 Bearing 838-832 Inch Taper Roller Bearing 3.1875 Bore
Cone Part Number: 838
Cup Part Number: 832
Inner (d): 80.963 mm/ 3.1875 in
Outer (D): 168.275 mm/ 6.6250 in
Width (T): 53.975 mm/ 2.1250 in
Mass: 5.52kg/ 12.170lb
Warranty: 1 year
Shields: open without
838/832 Bearing Specification
838/832 bearing is made up of two primary, separable components: the cone assembly (inner ring) and the cup (outer ring).
Cone Part Number: 838
Cup Part Number: 832
Inner (d): 80.963 mm/ 3.1875 in
Outer (D): 168.275 mm/ 6.6250 in
Width (T): 53.975 mm/ 2.1250 in
Mass: 5.52kg/ 12.170lb
Warranty: 1 year
Radial Clearance: standard C0/CN
Shields: open without shields
Cage Material: pressed steel
Number of Row: single row
Material of Inner Ring, Outer Ring, and Rollers: bearing steel, 52100 steel
Benefits:
1. 838/832 bearing handles both radial and axial loads, making it ideal for demanding applications.
2. Delivers long-lasting performance with high-quality materials and robust construction.
3. Fits a wide range of uses, including automotive, industrial, agricultural, and construction machinery.
4. Maintains precise alignment and smooth operation, even at high speeds.
5. Bearing 838-832 offers easy replacement due to standardized dimensions.
Inch Tapered Roller Bearings We Supply:
| Model Number | Bore (mm) | Outer Dia (mm) | Bearing Width (mm) | Mass (kg) |
| 25877/25821 | 34.925 | 73.025 | 23.812 | 0.470 |
| HM89446/HM89410 | 34.925 | 76.200 | 29.370 | 0.640 |
| L44642/L44610 | 25.400 | 50.292 | 14.224 | 0.120 |
| JLM104948/JLM104910 | 50.000 | 82.000 | 21.500 | 0.430 |
| JLM506849/JLM506810 | 55.000 | 90.000 | 23.000 | 0.540 |
| M88046/M88010 | 31.750 | 68.262 | 22.225 | 0.390 |
| HM88649/HM88610 | 34.925 | 72.233 | 25.400 | 0.489 |
| M88043/M88010 | 30.163 | 68.263 | 22.225 | 0.402 |
| LM29749/LM29711 | 38.100 | 65.088 | 19.812 | 0.250 |
| M84548/M84510 | 25.400 | 57.150 | 19.431 | 0.244 |
| M86649/M86610 | 30.162 | 64.292 | 21.433 | 0.336 |
| M802048/M802011 | 41.275 | 82.550 | 26.543 | 0.641 |
| 15101/15245 | 25.400 | 61.999 | 19.050 | 0.300 |
| 15103/15243 | 26.157 | 61.913 | 19.050 | 0.290 |
| HM218248/HM218210 | 89.975 | 146.975 | 40.000 | 2.550 |
| HM518445/HM518410 | 88.900 | 152.400 | 39.688 | 2.928 |
| 45291/45220 | 57.150 | 104.775 | 30.163 | 1.098 |
| 47890/47820 | 92.075 | 146.050 | 33.338 | 2.080 |
| H715334/H715311 | 61.912 | 136.525 | 46.038 | 3.470 |
| H715343/H715311 | 68.262 | 136.525 | 46.038 | 3.230 |
| H715345/H715311 | 71.438 | 136.525 | 46.038 | 3.110 |
| HM516449/HM516410 | 82.550 | 133.350 | 39.688 | 2.100 |
| 6461/6420 | 76.200 | 149.225 | 53.975 | 4.260 |
| 555S/552A | 57.150 | 123.825 | 38.100 | 2.360 |
| 59187/59429 | 47.625 | 108.966 | 34.925 | 1.580 |
| 536/532X | 47.625 | 107.950 | 36.513 | 1.590 |
| 66187/66462 | 47.625 | 117.475 | 33.338 | 1.700 |
| 617/612 | 47.625 | 120.650 | 41.275 | 2.350 |
| 65390/65320 | 49.212 | 114.300 | 44.450 | 2.180 |
| HH506348/HH506310 | 49.212 | 114.300 | 44.450 | 2.260 |
| 546/532X | 49.982 | 107.950 | 36.513 | 1.540 |
| H715348/H715311 | 77.788 | 136.525 | 46.038 | 2.840 |
| 661/653 | 79.375 | 146.050 | 41.275 | 2.860 |
| 595A/593X | 79.375 | 150.000 | 35.992 | 2.820 |
| 595A/592AS | 79.375 | 152.400 | 35.717 | 2.940 |
| 661/652 | 79.375 | 152.400 | 41.275 | 3.230 |
| 756A/752 | 79.375 | 161.925 | 47.625 | 4.490 |
| 838/832 | 80.963 | 168.275 | 53.975 | 5.520 |
Questions that usually come up before ordering 838/832 and 838-832
When is 838/832 and 838-832 worth comparing against nearby taper roller bearings options?
Comparison helps when dimensional fit is only part of the decision and load direction, sealing, clearance, speed, temperature, or repeat-order stability still need to be confirmed. Reviewing one or two nearby options early usually reduces sourcing mistakes later.
What details usually matter before approving 838/832 and 838-832 for repeat supply?
Buyers normally confirm the part reference, main dimensions, application, speed range, operating environment, sealing needs, and any packaging or marking requirements. That gives the supplier a cleaner basis for confirming availability and suitable alternatives.
Which next step usually helps after 838/832 and 838-832 is shortlisted?
A quick review of Taper Roller Bearings, one more commercial destination, and one practical guide usually saves time. That combination helps separate simple replacement orders from jobs that still need fit or application review.
Why keep a supporting guide linked beside 838/832 and 838-832?
Because it makes later decisions faster. When sizing notes, application cues, and nearby options stay close to the product, engineering, purchasing, and maintenance teams can revisit the same logic without starting the review from zero.
Shipping Method:
1. Sea shipping for mass cargos (GW > 500KGS)
2. Air shipping (GW between 100KGS – 500 KGS)
3. Express, such as DHL, TNT, Fedex, UPS for small cargos ( GW < 100KGS)
4. If you have shipping agent in China, we can send goods to your shipping agent's warehouse
Payment Terms:
We accept T/T, W/U, PAYPAL, L/C etc
Buyer FAQ
Questions buyers ask before choosing the next bearing option
What should I confirm before ordering 838/832 Bearing 838-832 Inch Taper Roller Bearing 3.1875 Bore?
Confirm the bearing number, bore size, outside diameter, width, seal or shield type, cage material, clearance, precision level, quantity, and application. These details help prevent a size match from becoming a performance mismatch.
Can this bearing be matched for replacement or repeat supply?
Yes. Replacement and repeat orders are easier when the original marking, measured dimensions, photos, application, and quantity are available. If the marking is unclear, the team can start from the size and working condition.
Which product family does this bearing belong to?
This item is handled within the Taper Roller Bearings family. Comparing the family page can help buyers review similar sizes, seal options, load direction, and related bearing choices before requesting a quote.
What affects price and lead time for this bearing?
Price and lead time can change with quantity, stock availability, precision grade, clearance, material, cage, seal or shield type, lubrication, packaging, and whether the order needs standard matching or custom production.
How is this bearing checked before delivery?
Inspection can include material review, dimensional measurement, noise and vibration checks, surface and crack checks, visual review, and packaging inspection according to the confirmed order requirements.
