230/500 CAK/C3W33 Bearing 230/500CAK/W33 Roller Bearing

230/500 CAK/C3W33 Bearing Specification:

230/500 CAK/C3W33 bearing is a double-row spherical roller bearing.
Regarding this bearing model,
Innder Diameter: 500mm
Outer Diameter: 720mm
Width: 167mm
Mass: 225kg
Cage: brass cage
Bearing Material bearing steel
Internal Play: C3 or C0
Precision: P0, P6, P5
CA: machined brass cage
K: tapered bore, 1:12
C3: internal play larger than C0
W33: lubrication groove and holes in the outer ring
Temperature Range: -30 °C to 120 °C

Key Benefits:

1. Supports very high radial loads thanks to its strong spherical structure, making it ideal for heavy-duty machinery and applications requiring maximum load capacity and stability.
2. Capable of accommodating axial forces in both directions, providing greater flexibility and ensuring smooth operation even in complex load conditions.
3. The concave, spherical outer raceway compensates for misalignment and shaft deflections, which helps prevent damage and extends the overall lifespan of the bearing.
4. Bearing 230/500CAK/W33 is designed to perform reliably in demanding environments such as elevators, textile machinery, food processing equipment, and cranes, ensuring safety and operational efficiency under tough conditions.

FAQ:

Q1: What type of bearing is this bearing?
A: The 230/500 CAK/C3W33 is a spherical roller bearing designed for heavy-duty applications involving high radial and axial loads.

Q2: What are the key applications of this bearing?
A: It is commonly used in industrial machinery, cranes, elevators, construction equipment, mining equipment and other heavy-duty equipment needing reliable load support.

Q3: What do the specifications “C3” and “W33” mean?
A: “C3” indicates a greater internal clearance for better accommodating shaft expansion and misalignment, while “W33” indicates the presence of a lubrication groove and holes in the outer ring.

Q4: Can this bearing operate at high speeds?
A: While designed for high load capacity, it is mainly intended for heavy-duty, moderate-speed applications rather than extremely high-speed operations.

Q5: What are the main benefits of using this bearing?
A: It supports heavy radial and axial loads, compensates for misalignment, and offers durability and reliability in harsh environments.
