LM29749-LM29710 Bearing SET70 Tapered Roller Bearing LM29749/10
Cone Number: LM29749
Cup Number: LM29710
Bore (d): 1-1/2 in/ 38.10 mm
Outer Diameter (D): 2.5625 in/ 65.088 mm
Cone Width (B): 0.7200 in/18.288 mm
Total Width (T): 0.71 in/ 18.034 mm
Mass: 0.235kg
LM29749-LM29710 Bearing Specification:
LM29749-LM29710 bearing set includes both the cone and the cup.
Regarding this bearing model number,
Cone Number: LM29749
Cup Number: LM29710
Bore (d): 1-1/2 in/ 38.10 mm
Outer Diameter (D): 2.5625 in/ 65.088 mm
Cone Width (B): 0.7200 in/18.288 mm
Total Width (T): 0.71 in/ 18.034 mm
Mass: 0.235kg
Cage: stamped steel
Bearing Material: bearing steel
Design Unit: inch
Seal Type: open
Precision: ABEC1, P0
Equivalents: LM29749 – LM29710, LM29749/LM29710, LM29749/10, SET70, Set 70, LM29749-20024 / 710-20024, LM29749-99401
Key Features:
1. Tapered roller bearing set: Supplied as a matched cone (LM29749) and cup (LM29710).
2. Handles combined loads: Designed to carry high radial loads plus axial (thrust) loads in one direction.
3. High load capacity: Tapered roller geometry provides strong load distribution for demanding duty.
4. Supports high rigidity: Helps reduce deflection under load, improving stability and performance.
5. Smooth running & efficient: Rolling contact reduces friction and heat generation versus plain bearings.
6. Adjustable clearance/preload: Can be set during installation to control end play and optimize service life.
7. Durable for heavy-duty use: Commonly used in wheel hubs, axles, gearboxes, and industrial equipment.
FAQs:
1) What type of bearing is LM29749/LM29710?
LM29749/LM29710 is a tapered roller bearing set, supplied as a matched cone (LM29749) and cup (LM29710).
2) What loads can it handle?
It’s designed for high radial loads and axial (thrust) loads in one direction. For axial loads in both directions, it’s commonly used as a pair (opposed mounting).
3) What’s the difference between ordering “LM29749” vs “LM29710”?
LM29749 = the cone (inner ring + rollers + cage)
LM29710 = the cup (outer ring)
4) How long does it take for you to ship my order?
We keep a large inventory of common ball bearings and roller bearings. For example, we currently have 456 pcs of LM603049–LM603012, 533 pcs of JL68145/JL68111Z, and 657 pcs of 386A in stock. In general, orders can be shipped within 3 business days after payment is received.
Questions buyers ask when LM29749-LM29710 and SET70 is still under review
When is LM29749-LM29710 and SET70 worth comparing against nearby taper roller bearings options?
Comparison helps when dimensional fit is only part of the decision and load direction, sealing, clearance, speed, temperature, or repeat-order stability still need to be confirmed. Reviewing one or two nearby options early usually reduces sourcing mistakes later.
What details usually matter before approving LM29749-LM29710 and SET70 for repeat supply?
Buyers normally confirm the part reference, main dimensions, application, speed range, operating environment, sealing needs, and any packaging or marking requirements. That gives the supplier a cleaner basis for confirming availability and suitable alternatives.
Which next step usually helps after LM29749-LM29710 and SET70 is shortlisted?
A quick review of Taper Roller Bearings, one more commercial destination, and one practical guide usually saves time. That combination helps separate simple replacement orders from jobs that still need fit or application review.
Why keep a supporting guide linked beside LM29749-LM29710 and SET70?
Because it makes later decisions faster. When sizing notes, application cues, and nearby options stay close to the product, engineering, purchasing, and maintenance teams can revisit the same logic without starting the review from zero.
