LM603049-LM603012 Bearing LM603049/12 Taper Roller Bearing Set36

LM603049-LM603012 Bearing Specification:

LM603049–LM603012 bearing comes as a matched cone and cup set.
Regarding this bearing model number,
Cone Number: LM603049
Cup Number: LM603012
d: 45.242mm
D: 77.788mm
B: 19.842mm
Mass: 0.381kg/ 0.84lb
Cage: stamped steel
Material: chrome steel
Seal Type: open
Lubrication: grease/oil
Precision: ABEC1, P0
Category: single row taper roller bearing
Equivalents: LM603049/LM603012, LM603049/12, LM603049/012, SET36, SET 36, HI-CAP LM 603049/12

Typical Applications:

• Trailer wheel hubs
• Automotive wheel ends / axles
• Agricultural equipment
• Gearboxes and industrial rotating equipment

Bearing Key Features:

• Single-row tapered roller bearing with tapered rollers and conical raceways
• Handles combined loads and supports high radial loads plus high axial load in one direction
• Increases axial load capacity with a larger contact angle
• Simplifies installation and removal with a two-piece cup-and-cone design
• Uses an open design, suited for applications with proper lubrication and sealing
