d: 39.688mm
D: 73.025mm
T: 25.654mm
Mass: 0.43kg/set
Cone: M201047
Cup: M201011
Numer of Row: single
Operating temperature: -40 °C to 120 °C
Bearing M201047 – M201011 is designed to handle both radial and axial loads.
For this bearing,
d: 39.688mm
D: 73.025mm
T: 25.654mm
Mass: 0.43kg/set
Cone: M201047
Cup: M201011
Numer of Row: single
Structure: tapered roller bearing
Precision level: P0, ABEC1
Also known as: M201047-M201011, M201047/M201011, M201047 / M201011, M201047/11
| Model Number | Boundary Dimension (mm) | Mass (KG) | ||
| d | D | T | ||
| L45449/L45410 | 29.000 | 50.292 | 14.224 | 0.113 |
| M201047/M201011 | 39.688 | 73.025 | 25.654 | 0.430 |
| U399/K426898 | 36.690 | 73.030 | 22.230 | 0.360 |
| JL69349/JL69310 | 38.000 | 63.000 | 17.000 | 0.200 |
| LM12749/LMl 2710 | 21.987 | 45.237 | 15.494 | 0.120 |
| L68149/L68110 | 34.987 | 59.131 | 15.875 | 0.170 |
| L44643/L44610 | 25.400 | 50.292 | 14.224 | 0.130 |
| 07100/07196 | 25.000 | 50.000 | 13.500 | 0.119 |
| LM12749/LM12711 | 21.987 | 45.974 | 15.494 | 0.120 |
| LM102949/LM102910 | 45.242 | 73.431 | 19.558 | 0.320 |
| LM102949/LM102911 | 45.242 | 73.431 | 21.430 | 0.330 |
| L68149/L68111 | 34.989 | 59.974 | 15.875 | 0.170 |
| 1988/1922 | 28.575 | 57.150 | 19.845 | 0.220 |
| LM67048/LM67010 | 31.750 | 59.131 | 15.875 | 0.183 |
| LM603049/LM603011 | 45.242 | 77.788 | 19.842 | 0.370 |
| LM104949/LM104911 | 50.800 | 82.550 | 21.590 | 0.420 |
| 15123/15245 | 31.750 | 62.000 | 18.161 | 0.230 |
| LM501349A/LM501310 | 41.275 | 73.431 | 19.558 | 0.330 |
| LM29748/LM29710 | 38.100 | 65.088 | 18.034 | 0.220 |
| M88048/M88010 | 33.338 | 68.262 | 22.225 | 0.380 |
| HM903249/HM903210 | 44.450 | 95.250 | 30.958 | 1.000 |
| M86647/M86610 | 28.575 | 64.292 | 21.433 | 0.350 |
| HM88649/HM88610 | 34.925 | 72.233 | 25.400 | 0.490 |
| LM501349/LM501310 | 41.275 | 73.431 | 19.558 | 0.330 |
| LM501349/LM501314 | 41.275 | 73.431 | 21.430 | 0.360 |
| LM501349/LM501311 | 41.275 | 73.431 | 23.012 | 0.370 |
| LM29749/LM29711 | 38.100 | 65.088 | 19.812 | 0.250 |
| 55200/55437 | 50.800 | 111.125 | 30.162 | 1.340 |
| HM88542/HM88510 | 31.750 | 73.025 | 29.370 | 0.610 |
| LM104949/LM104910 | 50.800 | 82.000 | 21.976 | 0.420 |
| 25877/25821 | 34.925 | 73.025 | 23.812 | 0.470 |
| HM89446/HM89410 | 34.925 | 76.200 | 29.370 | 0.650 |
| L44642/L44610 | 25.400 | 50.292 | 14.224 | 0.120 |
| JLM104948/JLM104910 | 50.000 | 82.000 | 21.500 | 0.420 |
| JLM506849/JLM506810 | 55.000 | 90.000 | 23.000 | 0.556 |
| M88046/M88010 | 31.750 | 68.263 | 22.225 | 0.390 |
Q1: What is the delivery time for an order?
A: We currently have 1,300 units of the M201047/M201011 roller bearing in stock. For orders up to this quantity, delivery can be arranged within 2–3 days after payment is received. For quantities exceeding 1,300 pieces, the delivery time will be between 10 and 25 days.
Q2: Do your bearings include a warranty?
A: Yes, our M201047/11 bearings come with a 1-year warranty for your peace of mind.
Q3: What shipping options are available?
A: We provide a range of shipping methods, including express services such as DHL, UPS, and FedEx, as well as air and sea freight. The best option will depend on your order’s total weight and your preferred shipping budget.
Comparison helps when dimensional fit is only part of the decision and load direction, sealing, clearance, speed, temperature, or repeat-order stability still need to be confirmed. Reviewing one or two nearby options early usually reduces sourcing mistakes later.
Buyers normally confirm the part reference, main dimensions, application, speed range, operating environment, sealing needs, and any packaging or marking requirements. That gives the supplier a cleaner basis for confirming availability and suitable alternatives.
A quick review of Taper Roller Bearings, one more commercial destination, and one practical guide usually saves time. That combination helps separate simple replacement orders from jobs that still need fit or application review.
Because it makes later decisions faster. When sizing notes, application cues, and nearby options stay close to the product, engineering, purchasing, and maintenance teams can revisit the same logic without starting the review from zero.
1. Sea shipping for mass cargos (GW > 500KGS)
2. Air shipping (GW between 100KGS – 500 KGS)
3. Express, such as DHL, TNT, Fedex, UPS for small cargos ( GW < 100KGS)
4. If you have shipping agent in China, we can send goods to your shipping agent's warehouse
We accept T/T, W/U, PAYPAL, L/C etc
Buyer FAQ
Confirm the bearing number, bore size, outside diameter, width, seal or shield type, cage material, clearance, precision level, quantity, and application. These details help prevent a size match from becoming a performance mismatch.
Yes. Replacement and repeat orders are easier when the original marking, measured dimensions, photos, application, and quantity are available. If the marking is unclear, the team can start from the size and working condition.
This item is handled within the Taper Roller Bearings family. Comparing the family page can help buyers review similar sizes, seal options, load direction, and related bearing choices before requesting a quote.
Price and lead time can change with quantity, stock availability, precision grade, clearance, material, cage, seal or shield type, lubrication, packaging, and whether the order needs standard matching or custom production.
Inspection can include material review, dimensional measurement, noise and vibration checks, surface and crack checks, visual review, and packaging inspection according to the confirmed order requirements.
