32210JR Bearing 32210 Roller Bearing 50X90X24.75mm

d: 50mm/ 1.9685in
D: 90mm/ 3.5433in
T: 24.75mm/ 0.9744in
B: 23mm/ 0.9055in
Mass: 0.617kg/ 1.36lb
Precision: P0, P6, P5
J: tapered roller bearing compliant with ISO R355 (metric series, sub-unit)
R: internal design code (enhanced load capacity).

Description



32210JR Bearing Description:

32210JR bearing is single row taper roller bearing,
d: 50mm/ 1.9685in
D: 90mm/ 3.5433in
T: 24.75mm/ 0.9744in
B: 23mm/ 0.9055in
Mass: 0.617kg/ 1.36lb
Precision: P0, P6, P5
J: tapered roller bearing compliant with ISO R355 (metric series, sub-unit)
R: internal design code (enhanced load capacity).
Equivalents: 32210-A, HR32210J, 4T-32210, 32210, 32210 JR, 7510E, 7510 E

Key Features:

1. Handles combined loads: Bearing 32210 is designed to support both high radial and axial loads in one direction.
2. Axial load capacity increases with a greater contact angle.
3. Easy to assemble and disassemble due to its separable cup (outer ring) and cone (inner ring with cage and rollers) design.
4. Open design requires installation in a mirror-image arrangement with a second bearing for proper function.
5. Versatile mounting options: Can be mounted in X, O, or tandem arrangements for paired bearing sets.

Other Metric Series Taper Roller Bearings We Provide:

New Model Old Model Dimensions (dxDxB) Mass (kg)
32203 7503E 17×40×17.25 0.104
32204 7504E 20×47×19.25 0.158
32205 7505E 25×52×19.25 0.199
32206 7506E 30×62×21.25 0.282
32207 7507E 35×72×24.25 0.449
32208 7508E 40×80×24.75 0.533
32209 7509E 45×85×24.75 0.583
32210 7510E 50×90×24.75 0.614
32211 7511E 55×100×26.75 0.849
32212 7512E 60×110×29.75 1.100
32213 7513E 65×120×32.75 1.570
32214 7514E 70×125×33.25 1.560
32215 7515E 75×130×33.25 1.560
32216 7516E 80×140×32.25 2.000
32217 7517E 85×150×38.5 2.690
32218 7518E 90×160×42.5 3.300
32219 7519E 95×170×45.5 4.180
32220 7520E 100×180×40 5.140
32221 7521E 105×90×53 6.340
32222 7522E 110×200×56 7.430
32224 7524E 120×215×61.5 9.600
32226 7526EY 130×230×67.75 11.900
32228 7528E 140×250×71.75 14.700
32230 7530E 150×270×77 18.200
32232 7532E 160×290×84 21.100
32234 7534E 170×310×91 28.600
32236 7536E 180×320×91 29.800
32238 7538E 190×340×97 35.700
32240 7540E 200×360×104 42.500
32244 7544E 220×400×115 48.100
FAQ:

Q1: What is the delivery time if we place an order?
A: We currently have 2350 pieces of the 32210 roller bearing in stock. If your order quantity is less than 2350 pieces, delivery will be within 2-3 days after payment. For orders over 2350 pieces, the delivery time is 10-20 days.

Q2: What are your payment terms?
A: We accept payment via T/T, Western Union, or PayPal.

Q3: Do your bearings come with a warranty?
A: Yes, our 32210 JR roller bearings come with a 1-year warranty.
