LM501349/LM501311 Bearing LM501349-LM501311 Roller Bearing
Bore: 41.275 mm/ 1.6250 in
Outer Diameter: 73.431 mm/ 2.8910 in
Bearing Width: 23.012 mm/ 0.9060 in
Mass: 0.816lb/ 0.37kg
Cone Number: LM501349
Cup Number: LM501311
Cage Material: stamped steel
Bearing Material: bearing steel
LM501349/LM501311 Bearing Specification:
LM501349/LM501311 bearing is an inch-sized tapered roller bearing.
The specifications are as follows:
| Bore: | 41.275 mm/ 1.6250 in |
| Outer Diameter: | 73.431 mm/ 2.8910 in |
| Bearing Width: | 23.012 mm/ 0.9060 in |
| Mass: | 0.816lb/ 0.37kg |
| Cone Number: | LM501349 |
| Cup Number: | LM501311 |
| Cage Material: | stamped steel |
| Bearing Material: | bearing steel |
| Warranty: | 1 year |
| Certificate: | ISO9001: 2015 |
| Interchange Numbers: | LM501349 / LM501311 |
| LM501349-LM501311 | |
| LM501349 – LM501311 | |
| LM501349/11 |
Key Benefits:
1. Handles Heavy Loads – The LM501349/LM501311 bearing supports both radial and axial loads, making it ideal for demanding applications.
2. Delivers Long Service Life – The cup and cone design ensures strength and durability, even in harsh operating environments.
3. Provides Reliable Performance – Bearing LM501349 – LM501311 maintains stability and smooth operation under continuous heavy-duty use.
4. Fits Diverse Applications – Users can use LM501349/11 bearings in automotive, industrial, and agricultural machinery with consistent results.
5. Reduces Maintenance Needs – Its robust design minimizes wear, helping you cut downtime and extend equipment life.
Imperial Tapered Roller Bearings – Explore Our Models:
| LM501349/LM501310 | 41.275 | 73.431 | 19.558 | 0.330 |
| LM501349/LM501314 | 41.275 | 73.431 | 21.430 | 0.360 |
| LM501349/LM501311 | 41.275 | 73.431 | 23.012 | 0.370 |
| LM29749/LM29711 | 38.100 | 65.088 | 19.812 | 0.250 |
| 55200/55437 | 50.800 | 111.125 | 30.162 | 1.340 |
| HM88542/HM88510 | 31.750 | 73.025 | 29.370 | 0.610 |
| LM104949/LM104910 | 50.800 | 82.000 | 21.976 | 0.420 |
| 25877/25821 | 34.925 | 73.025 | 23.812 | 0.470 |
| HM89446/HM89410 | 34.925 | 76.200 | 29.370 | 0.650 |
| L44642/L44610 | 25.400 | 50.292 | 14.224 | 0.120 |
| JLM104948/JLM104910 | 50.000 | 82.000 | 21.500 | 0.420 |
| JLM506849/JLM506810 | 55.000 | 90.000 | 23.000 | 0.556 |
| M88046/M88010 | 31.750 | 68.263 | 22.225 | 0.390 |
| HM88649/HM88610 | 34.925 | 72.233 | 25.400 | 0.489 |
| M88043/M88010 | 30.163 | 68.263 | 22.225 | 0.414 |
| LM29749/LM29711 | 38.100 | 65.088 | 19.812 | 0.250 |
| M84548/M84510 | 25.400 | 57.150 | 19.431 | 0.244 |
| M86649/M86610 | 30.162 | 64.292 | 21.433 | 0.336 |
| HM89449/HM89410 | 36.512 | 76.200 | 29.370 | 0.626 |
| M802048/M802011 | 41.275 | 82.550 | 26.543 | 0.641 |
| 15101/15245 | 25.400 | 61.999 | 19.050 | 0.290 |
| 15103/15243 | 26.157 | 61.913 | 19.050 | 0.290 |
| 580/572 | 82.550 | 139.700 | 36.512 | 2.190 |
| 582/572 | 82.550 | 139.992 | 36.512 | 2.200 |
| 594A/592A | 95.250 | 152.400 | 39.688 | 2.550 |
| 598A/592A | 92.075 | 152.400 | 39.688 | 2.630 |
| 663/653 | 82.550 | 146.050 | 41.275 | 2.790 |
| 3782/3720 | 44.450 | 93.264 | 30.162 | 0.959 |
Questions buyers ask when LM501349/LM501311 and LM501349-LM501311 is still under review
When is LM501349/LM501311 and LM501349-LM501311 worth comparing against nearby taper roller bearings options?
Comparison helps when dimensional fit is only part of the decision and load direction, sealing, clearance, speed, temperature, or repeat-order stability still need to be confirmed. Reviewing one or two nearby options early usually reduces sourcing mistakes later.
What details usually matter before approving LM501349/LM501311 and LM501349-LM501311 for repeat supply?
Buyers normally confirm the part reference, main dimensions, application, speed range, operating environment, sealing needs, and any packaging or marking requirements. That gives the supplier a cleaner basis for confirming availability and suitable alternatives.
Which next step usually helps after LM501349/LM501311 and LM501349-LM501311 is shortlisted?
A quick review of Taper Roller Bearings, one more commercial destination, and one practical guide usually saves time. That combination helps separate simple replacement orders from jobs that still need fit or application review.
Why keep a supporting guide linked beside LM501349/LM501311 and LM501349-LM501311?
Because it makes later decisions faster. When sizing notes, application cues, and nearby options stay close to the product, engineering, purchasing, and maintenance teams can revisit the same logic without starting the review from zero.
Shipping Method:
1. Sea shipping for mass cargos (GW > 500KGS)
2. Air shipping (GW between 100KGS – 500 KGS)
3. Express, such as DHL, TNT, Fedex, UPS for small cargos ( GW < 100KGS)
4. If you have shipping agent in China, we can send goods to your shipping agent's warehouse
Payment Terms:
We accept T/T, W/U, PAYPAL, L/C etc
Buyer FAQ
Questions buyers ask before choosing the next bearing option
What should I confirm before ordering LM501349/LM501311 Bearing LM501349-LM501311 Roller Bearing?
Confirm the bearing number, bore size, outside diameter, width, seal or shield type, cage material, clearance, precision level, quantity, and application. These details help prevent a size match from becoming a performance mismatch.
Can this bearing be matched for replacement or repeat supply?
Yes. Replacement and repeat orders are easier when the original marking, measured dimensions, photos, application, and quantity are available. If the marking is unclear, the team can start from the size and working condition.
Which product family does this bearing belong to?
This item is handled within the Taper Roller Bearings family. Comparing the family page can help buyers review similar sizes, seal options, load direction, and related bearing choices before requesting a quote.
What affects price and lead time for this bearing?
Price and lead time can change with quantity, stock availability, precision grade, clearance, material, cage, seal or shield type, lubrication, packaging, and whether the order needs standard matching or custom production.
How is this bearing checked before delivery?
Inspection can include material review, dimensional measurement, noise and vibration checks, surface and crack checks, visual review, and packaging inspection according to the confirmed order requirements.
Need help checking fit, price, or lead time? Request a bearing quote
