Bearing Cone: LL225749
Bearing Cup: LL225710
Bore (d): 127mm/ 5 inch
Outer Diameter (D): 165.895mm/ 6.5313 inch
Cone Width (B): 17.463mm/ 0.6875 inch
Bearing Total Width (T): 18.258mm/ 0.7188 inch
Mass: 0.92kg/ 2.028lb
LL225749-LL225710 Bearing Cone: LL225749
Bearing Cup: LL225710
Bore (d): 127mm/ 5 inch
Outer Diameter (D): 165.895mm/ 6.5313 inch
Cone Width (B): 17.463mm/ 0.6875 inch
Bearing Total Width (T): 18.258mm/ 0.7188 inch
Mass: 0.92kg/ 2.028lb
Seals: without
Material: chrome steel
Number of Row: single row
Catergory: imperial taper roller bearing
Precision: standard precision ABEC1, P0
Certificate: ISO9001: 2015
Warranty: 1 year
Also Known As: LL225749 – LL225710, LL225749/LL225710, LL225749/710, LL225749-99401, LL225749-9X032, etc
| Model Number | Dimensions(d*D*B)/mm | Mass/ kg |
| L225749/L225710 | 127.000×165.895×18.258 | 0.920 |
| L225849/L225810 | 127.000×169.862×25.400 | 1.610 |
| L725349/L725311 | 127.000×171.450×25.400 | 1.500 |
| LM125748/LM125711 | 127.000×174.625×36.512 | 2.540 |
| L225849/L225818 | 127.000×180.975×25.400 | 2.100 |
| 48290/48220 | 127.000×182.562×39.688 | 3.270 |
| 67388/67322 | 127.000×196.850×46.038 | 5.010 |
| 67388/67320 | 127.000×203.200×46.038 | 5.610 |
| 74500/74850 | 127.000×215.900×47.625 | 7.010 |
| 97500/97900 | 127.000×228.600×53.975 | 8.240 |
| HM926747/HM926710 | 127.000×228.600×53.975 | 8.610 |
| 95500/95925 | 127.000×234.950×63.500 | 11.730 |
| 95500/95962 | 127.000×244.475×63.500 | 13.080 |
| EE116050/116098 | 127.000×250.825×63.500 | 13.610 |
| 99500/99100 | 127.000×254.000×66.675 | 15.440 |
| HH228349/HH228310 | 127.000×254.000×77.788 | 17.700 |
| HH231637/HH231610 | 127.000×288.925×82.550 | 25.210 |
Q1: What type of bearing is the LL225749‑LL225710?
A1: It is a single‑row taper roller bearing (cup & cone set).
Q2: What are the typical applications?
A2: Taper roller bearings are widely used in gearboxes, axles, transmissions, heavy machinery, and other shafts requiring combined radial and axial support.
Q3: Is the bearing separable?
A3: Yes. The cone (inner ring, rollers, cage) and cup (outer ring) separate for easier mounting and maintenance.
Q4: What materials are typical?
A4: Rollers and rings use hardened bearing steel and cages use steel.
Q5: What is the lead time and stock availability?
A5: Lead time depends on stock. We keep large stock of common bearing models. If the item is in stock, lead time is normally within 3 working days after payment is received. Provide model and quantity and we will confirm current availability and delivery time.
1. Sea shipping for mass cargos (GW > 500KGS)
2. Air shipping (GW between 100KGS – 500 KGS)
3. Express, such as DHL, TNT, Fedex, UPS for small cargos ( GW < 100KGS)
4. If you have shipping agent in China, we can send goods to your shipping agent's warehouse
We accept T/T, W/U, PAYPAL, L/C etc
