CRL38 Bearing RLS22.1/2 Inch Roller Bearing LRJ4 3/4 4.75” Bore
Inner Diameter: 120.65mm/ 4.75 inch
Outer Diameter: 209.55mm/ 8.25 inch
Width: 33.34mm/ 1.3126 inch
Mass: 4.80 kg/ 10.582 lbs
Internal Play: standard CN, CO
Rings & Rollers Material: chrome steel
Hardness: 58-65 HRC
CRL38 Bearing Specification:
CRL38 bearing is a cylindrical roller bearing with inch-sized dimensions.
Inner Diameter: 120.65mm/ 4.75 inch
Outer Diameter: 209.55mm/ 8.25 inch
Width: 33.34mm/ 1.3126 inch
Mass: 4.80 kg/ 10.582 lbs
Internal Play: standard CN, C0
Rings & Rollers Material: chrome steel
Hardness: 58-65 HRC
Cage Material: brass
Certificate: ISO9001: 2015
Warranty: 1 year
Rolling Element: rollers
Bearing Structure: cylindrical roller bearing
Replacements: CRL38, RLS22.1/2, RLS 22.1/2, RLS 22-1/2, LRJ4 3/4, LRJ 4 3/4, LRJ 4-3/4
Variety of Inch Series Ball Bearings & Roller Bearings Offered:
| CRL 5 | RLS 7 | MRJ 1/2 | CRM 4 |
| CRL 6 | RLS 8 | MRJ 5/8 | CRM 5 |
| CRL 7 | RLS 9 | MRJ 3/4 | CRM 6 |
| CRL 8 | RLS 10 | MRJ 7/8 | CRM 7 |
| CRL 9 | RLS 11 | MRJ 1 | CRM 8 |
| CRL 10 | RLS 12 | MRJ 1 1/8 | CRM 9 |
| CRL 11 | RLS 12.1/2 | MRJ 1 1/4 | CRM 10 |
| CRL 12 | RLS 13 | MRJ 1 3/8 | CRM 11 |
| CRL 13 | RLS 13.1/2 | MRJ 1 1/2 | CRM 12 |
| CRL 14 | RLS 14 | MRJ 1 5/8 | CRM 13 |
| CRL 15 | RLS 14.1/2 | MRJ 1 3/4 | CRM 14 |
| CRL 16 | RLS 15 | MRJ 1 7/8 | CRM 15 |
| CRL 18 | RLS 16 | MRJ 2 | CRM 16 |
| CRL 20 | RLS 17 | MRJ 2 1/4 | CRM 18 |
| CRL 22 | RLS 18 | MRJ 2 1/2 | CRM 20 |
| CRL 24 | RLS 19 | MRJ 2 3/4 | CRM 22 |
| CRL 26 | RLS 19.1/2 | MRJ 3 | CRM 24 |
| CRL 28 | RLS 20 | MRJ 3 1/4 | CRM 26 |
| CRL 30 | RLS 20 1/2 | MRJ 3 3/8 | CRM 27 |
| CRL 32 | RLS 21 | MRJ 3 1/2 | CRM 28 |
| CRL 34 | RLS 21.1/2 | MRJ 3 3/4 | CRM 30 |
| CRL 36 | RLS 22 | MRJ 4 | CRM 32 |
| CRL 38 | RLS 22.1/2 | MRJ 4 1/4 | CRM 34 |
| CRL 40 | RLS 23 | MRJ 4 1/2 | CRM 36 |
| CRL 44 | RLS 23.1/2 | MRJ 4 3/4 | CRM 38 |
| CRL 48 | RLS 24 | MRJ 5 | CRM 40 |
| CRL 52 | RLS 24.1/2 | MRJ 5 1/2 | CRM 44 |
| CRL 56 | RLS 25 | MRJ 6 | CRM 48 |
Why Partner With Us?
Questions that usually come up before ordering CRL38 and RLS22
When is CRL38 and RLS22 worth comparing against nearby cylindrical roller bearings options?
Comparison helps when dimensional fit is only part of the decision and load direction, sealing, clearance, speed, temperature, or repeat-order stability still need to be confirmed. Reviewing one or two nearby options early usually reduces sourcing mistakes later.
What details usually matter before approving CRL38 and RLS22 for repeat supply?
Buyers normally confirm the part reference, main dimensions, application, speed range, operating environment, sealing needs, and any packaging or marking requirements. That gives the supplier a cleaner basis for confirming availability and suitable alternatives.
Which next step usually helps after CRL38 and RLS22 is shortlisted?
A quick review of Cylindrical Roller Bearings, one more commercial destination, and one practical guide usually saves time. That combination helps separate simple replacement orders from jobs that still need fit or application review.
Why keep a supporting guide linked beside CRL38 and RLS22?
Because it makes later decisions faster. When sizing notes, application cues, and nearby options stay close to the product, engineering, purchasing, and maintenance teams can revisit the same logic without starting the review from zero.
Shipping Method:
1. Sea shipping for mass cargos (GW > 500KGS)
2. Air shipping (GW between 100KGS – 500 KGS)
3. Express, such as DHL, TNT, Fedex, UPS for small cargos ( GW < 100KGS)
4. If you have shipping agent in China, we can send goods to your shipping agent's warehouse
Payment Terms:
We accept T/T, W/U, PAYPAL, L/C etc
Buyer FAQ
Questions buyers ask before choosing the next bearing option
What should I confirm before ordering CRL38 Bearing RLS22.1/2 Inch Roller Bearing LRJ4 3/4 4.75” Bore?
Confirm the bearing number, bore size, outside diameter, width, seal or shield type, cage material, clearance, precision level, quantity, and application. These details help prevent a size match from becoming a performance mismatch.
Can this bearing be matched for replacement or repeat supply?
Yes. Replacement and repeat orders are easier when the original marking, measured dimensions, photos, application, and quantity are available. If the marking is unclear, the team can start from the size and working condition.
Which product family does this bearing belong to?
This item is handled within the Cylindrical Roller Bearings family. Comparing the family page can help buyers review similar sizes, seal options, load direction, and related bearing choices before requesting a quote.
What affects price and lead time for this bearing?
Price and lead time can change with quantity, stock availability, precision grade, clearance, material, cage, seal or shield type, lubrication, packaging, and whether the order needs standard matching or custom production.
How is this bearing checked before delivery?
Inspection can include material review, dimensional measurement, noise and vibration checks, surface and crack checks, visual review, and packaging inspection according to the confirmed order requirements.
Need help checking fit, price, or lead time? Request a bearing quote
