567-563 Bearing 567/563 Taper Roller Bearing
Bore (d): 73.025 mm
Outer Diameter (D): 127.000 mm
Inner Ring Width (B): 36.170 mm
Total Width (T): 36.512 mm
Mass: 1.80kg/ 3.97lb
Cone Number: 567
Cup Number: 563
567-563 Bearing Information:
567-563 Bearing Bore (d): 73.025 mm
Outer Diameter (D): 127.000 mm
Inner Ring Width (B): 36.170 mm
Total Width (T): 36.512 mm
Mass: 1.80kg/ 3.97lb
Cone Number: 567
Cup Number: 563
Cage: steel
Bearing Material: bearing steel
Seal Type: open
Precision: ABEC1, P0
Category: single row taper roller bearing
Interchange Number: 567 – 563, 567/563, 567-99401, 567-90047, 567-99301, SET349, SET425
Key Features:
1. Designed to support combined radial and axial loads efficiently.
2. Precision roller and raceway design helps ensure low friction and consistent running performance.
3. Commonly used in automotive, agricultural machinery, construction equipment, gearboxes, and industrial machinery.
4. Offers a practical balance of load capacity, durability, and operating reliability for various mechanical applications.
Our Tapered Roller Bearing Range:
| SET55 25590/25523 | SET209 498/492A | SET266 29590/29522 |
| SET56 LM29748/LM29710 | SET210 527/522 | SET267 29685/29620 |
| SET57 31594/31520 | SET211 528/522 | SET268 LM29749/LM29711 |
| SET58 LM48548A/LM48510 | SET212 537/532X | SET269 33281/33462 |
| SET59 LM48548A/LM48511A | SET213 539/532A | SET270 33885/33822 |
| SET60 LM48548/LM48511A | SET214 559/552A | SET271 33889/33822 |
| SET61 11590/11520 | SET215 575/572X | SET272 33895/33822 |
| SET62 17887/17831 | SET216 594/592A | SET273 34301/34500 |
| SET63 M88048/M88010 | SET217 598A/593X | SET274 36690/36620 |
| SET64 HM903249/HM903210 | SET218 641/632 | SET275 37425/37625 |
| SET65 M86647/M86610 | SET219 M88046/M88010 | SET276 39580/39520 |
| SET66 368S/362 | SET220 681/672 | SET277 39580/39528 |
| SET67 HM88649/HM88610 | SET222 HM88649HP/HM88610P | SET278 39581/39520 |
| SET68 497/493 | SET223 750A/742 | SET279 39585/39520 |
| SET69 LM501349/LM501314 | SET224 855/854 | SET280 U298/U261L(K529698) |
| SET70 LM29749/LM29710 | SET225 861/854 | SET281 42381/42584 |
| SET71 LM67049A/LM67010 | SET226 1380/1328 | SET282 42688/42620 |
Shipping Method:
1. Sea shipping for mass cargos (GW > 500KGS)
2. Air shipping (GW between 100KGS – 500 KGS)
3. Express, such as DHL, TNT, Fedex, UPS for small cargos ( GW < 100KGS)
4. If you have shipping agent in China, we can send goods to your shipping agent's warehouse
Payment Terms:
We accept T/T, W/U, PAYPAL, L/C etc
