47686/47620 Bearing SET411 Taper Roller Bearing 47686/20
Bearing Cone: 47686
Bearing Cup: 47620
Inner Diameter (d): 82.55 mm/ 3-1/4 inch
Outer Diameter (D): 133.35 mm/ 5-1/4 inch
Cone Width (B): 33.338 mm/ 1.3125 inch
Mass: 1.72kg/ 3.792lb
Cage: steel
Bearing Material: chrome steel
47686/47620 Bearing Specification:
47686/47620 Bearing Cone: 47686
Bearing Cup: 47620
Inner Diameter (d): 82.55 mm/ 3-1/4 inch
Outer Diameter (D): 133.35 mm/ 5-1/4 inch
Cone Width (B): 33.338 mm/ 1.3125 inch
Mass: 1.72kg/ 3.792lb
Cage: steel
Bearing Material: 52100 bearing steel
Seal Type: without
Relubricate Holes: without
Precision: standard ABEC1, P0
Category: inch tapered roller bearing
Operating Temperature: -30 °C to 120 °C
Replacements: 47686 / 47620, 47686-47620, 47686 – 47620, 47686/20, 47686/620, SET411, Set 411, SET411-900SA, 4T-47686/47620
47686 / 47620 Applications:
Heavy-duty Vehicles: Compatible with trucks, trailers, and other commercial vehicles requiring robust bearing support.
Agricultural Equipment: Suitable for tractors, harvesters, and other agricultural machinery that operate under heavy loads and tough conditions.
Heavy Machinery: Used in construction and mining equipment to support large loads and ensure smooth operation in demanding environments.
Industrial Gearboxes: Essential in gear reducers and transmissions where high torque and durability are required.
Imperial Taper Roller Bearing Cross-Reference Table:
| SET401 | 580/572 |
| SET402 | 582/572 |
| SET403 | 594A/592A |
| SET404 | 598A/592A |
| SET405 | 663/653 |
| SET406 | 3782/3720 |
| SET407 | 28622/28682 |
| SET408 | 39590/39520 |
| SET409 | 45220/45280 |
| SET410 | 45220/45284 |
| SET411 | 47686/47620 |
| SET412 | HM212047/HM212011 |
| SET413 | HM212049/HM212011 |
| SET414 | HM218248/HM218210 |
| SET415 | HM518445/HM518410 |
| SET416 | 45291/45220 |
| SET417 | 47890/47820 |
| SET418 | H715311/H715334 |
| SET419 | H715311/H715343 |
| SET420 | H715311/H715345 |
| SET421 | HM516410/HM516449A |
| SET422 | HM516410/HM516449C |
| SET423 | 6420/6461A |
| SET424 | 552A/555S |
| SET425 | 563/567 |
| SET426 | 47620/47679 |
Questions that help when 47686/47620 and SET411 is on the shortlist
When is 47686/47620 and SET411 worth comparing against nearby taper roller bearings options?
Comparison helps when dimensional fit is only part of the decision and load direction, sealing, clearance, speed, temperature, or repeat-order stability still need to be confirmed. Reviewing one or two nearby options early usually reduces sourcing mistakes later.
What details usually matter before approving 47686/47620 and SET411 for repeat supply?
Buyers normally confirm the part reference, main dimensions, application, speed range, operating environment, sealing needs, and any packaging or marking requirements. That gives the supplier a cleaner basis for confirming availability and suitable alternatives.
Which next step usually helps after 47686/47620 and SET411 is shortlisted?
A quick review of Taper Roller Bearings, one more commercial destination, and one practical guide usually saves time. That combination helps separate simple replacement orders from jobs that still need fit or application review.
Why keep a supporting guide linked beside 47686/47620 and SET411?
Because it makes later decisions faster. When sizing notes, application cues, and nearby options stay close to the product, engineering, purchasing, and maintenance teams can revisit the same logic without starting the review from zero.
Shipping Method:
1. Sea shipping for mass cargos (GW > 500KGS)
2. Air shipping (GW between 100KGS – 500 KGS)
3. Express, such as DHL, TNT, Fedex, UPS for small cargos ( GW < 100KGS)
4. If you have shipping agent in China, we can send goods to your shipping agent's warehouse
Payment Terms:
We accept T/T, W/U, PAYPAL, L/C etc
Buyer FAQ
Questions buyers ask before choosing the next bearing option
What should I confirm before ordering 47686/47620 Bearing SET411 Taper Roller Bearing 47686/20?
Confirm the bearing number, bore size, outside diameter, width, seal or shield type, cage material, clearance, precision level, quantity, and application. These details help prevent a size match from becoming a performance mismatch.
Can this bearing be matched for replacement or repeat supply?
Yes. Replacement and repeat orders are easier when the original marking, measured dimensions, photos, application, and quantity are available. If the marking is unclear, the team can start from the size and working condition.
Which product family does this bearing belong to?
This item is handled within the Taper Roller Bearings family. Comparing the family page can help buyers review similar sizes, seal options, load direction, and related bearing choices before requesting a quote.
What affects price and lead time for this bearing?
Price and lead time can change with quantity, stock availability, precision grade, clearance, material, cage, seal or shield type, lubrication, packaging, and whether the order needs standard matching or custom production.
How is this bearing checked before delivery?
Inspection can include material review, dimensional measurement, noise and vibration checks, surface and crack checks, visual review, and packaging inspection according to the confirmed order requirements.
Need help checking fit, price, or lead time? Request a bearing quote
