3193 Bearing Cone 1.25” Bore

3193 Bearing Cone Specification

3193 Bearing Cone Bore: 1.25 in/ 31.75mm
Cone Width: 1.181 in/ 29.997mm
Mass: 0.4kg
Cage: pressed steel
Precision: ABEC1, P0
Seals: without
Rolling Elements: rollers
Number of Row: single
Radial Internal Play: CN/C0
Working Temperature: –30 °C to +120 °C
Category: taper roller bearing cone
Bearing Part Numbers: 3193-3120, 3193-3126, 3193-3130

Key Features:

1. Durable tapered roller design for handling combined radial and axial loads.
2. High load-carrying capacity, suitable for demanding operating conditions.
3. Precision-machined raceway helps ensure smooth rotation and stable performance.
4. Reliable cone component for use with the matching bearing cup.
5. Good rigidity and alignment support in automotive and industrial assemblies.

FAQs:

Question 1: What is a 3193 bearing cone?
Answer: The 3193 bearing cone is the inner assembly of a tapered roller bearing. It includes the inner ring, rollers, and cage, and it works together with a matching bearing cup to support radial and axial loads.

Question 2: What applications use this cone?
Answer: The 3193 cones can be used in automotive, agricultural machinery, industrial equipment, trailers, gearboxes, and other mechanical systems that require strong load capacity and stable rotation.

Question 3: Should I replace the cone and cup together?
Answer: In most cases, replacing the bearing cone and cup together gives better performance and longer service life. Using a new cone with a worn cup may cause noise, vibration, or premature bearing failure.

Question 4: When can you ship my order after payment is completed?
Answer: Normally, we can ship your order within 3 business days after payment is received, as we keep a large stock of ball bearings and roller bearings. For example, we currently have 355 sets of BA240-3 WSA, 563 sets of 55175/55437, 728 sets of 524737D, 675 set BAH0051 and 471 sets of 22332MA in stock. For customized bearings, the lead time is usually 20–35 days, depending on the specific requirements and production schedule.
