22218CC/W33 Bearing 22218 CC/W33 Spherical Bearing

d: 90mm/ 3.5433 inch
D: 160mm/ 6.2992 inch
B: 40mm/ 1.5748 inch
Weight: 3.15kg
Bore: cylindrical bore
Lubrication: lubrication groove with 3 holes
Internal Play: standard CN or C3

Description



22218CC/W33 Bearing Specification

22218CC/W33 bearing is double row roller bearing structure
d: 90mm/ 3.5433 inch
D: 160mm/ 6.2992 inch
B: 40mm/ 1.5748 inch
Weight: 3.15kg
Bore: cylindrical bore
Seal: open without seal
Lubrication: lubrication groove with 3 holes
Internal Play: standard CN or C3
CC: two window-type steel cages, flangeless inner ring, and guide ring centered on the inner ring
W33: lubrication groove and three lubrication holes on the outer ring
Also Known As: 22218CC/W33, 22218 CC/W33, 22218CCW33, 22218 CCW33

Key Features:

1. Open design with solid inner and outer rings
2. Two rows of symmetrical rollers for enhanced load capacity
3. Spherical, concave raceway to compensate for misalignment and shaft deflection
4. 22218CC/W33 bearing withstands high radial loads and accommodates axial loads in both directions
5. Suitable for demanding applications such as elevators, textile machines, food processing equipment, and cranes

Spherical Roller Bearings in Stock:

Bearings NO. d/mm D/mm B/mm C/kN C0/kN Weight/kg
23120 CC/W33 100 165 52 365 490 4.55
23120 CCK/W33 100 165 52 365 490 4.4
23120-2CS2/VT143 100 165 52 365 490 4.4
24120 CC/W33 100 165 65 455 640 5.65
24120 CCK30/W33 100 165 65 455 640 5.55
22220 E 100 180 46 425 490 4.9
22220 EK 100 180 46 425 490 4.8
BS2-2220-2CS5/VT143 100 180 55 425 490 5.5
23220 CC/W33 100 180 60.3 475 600 6.85
23220 CCK/W33 100 180 60.3 475 600 6.65
23220-2CS 100 180 60.3 475 600 6.7
21320 E 100 215 47 425 490 8.6
21320 EK 100 215 47 425 490 8.5
22320 E 100 215 73 815 950 13.5
22320 EJA/VA405 100 215 73 815 950 13.5
22320 EK 100 215 73 815 950 13
22320 EKJA/VA405 100 215 73 815 950 13
23022 CC/W33 110 170 45 310 440 3.8
23022 CCK/W33 110 170 45 310 440 3.7
23022-2CS 110 170 45 310 440 3.75
24022 CC/W33 110 170 60 415 620 5
24022 CCK30/W33 110 170 60 415 620 4.9
23122 CC/W33 110 180 56 430 585 5.75
23122 CCK/W33 110 180 56 430 585 5.55
23122-2CS2/VT143 110 180 56 430 585 5.55
24122 CC/W33 110 180 69 520 750 7.1
24122 CCK30/W33 110 180 69 520 750 7
24122-2CS2/VT143 110 180 69 460 750 7
22222 E 110 200 53 560 640 7
22222 EK 110 200 53 560 640 6.85
BS2-2222-2CS5/VT143 110 200 63 560 640 7.6
23222 CC/W33 110 200 69.8 600 765 9.85
23222 CCK/W33 110 200 69.8 600 765 9.55
22322 E 110 240 80 950 1120 18.4
22322 EJA/VA405 110 240 80 950 1120 18.4
22322 EK 110 240 80 950 1120 18
22322 EKJA/VA405 110 240 80 950 1120 18
23024 CC/W33 120 180 46 355 510 4.2
23024 CCK/W33 120 180 46 355 510 4.05
23024-2CS2/VT143 120 180 46 355 510 4.2
24024 CC/W33 120 180 60 430 670 5.45
24024 CCK30/W33 120 180 60 430 670 5.35
24024-2CS2/VT143 120 180 60 430 670 5.45
23124 CC/W33 120 200 62 510 695 8
23124 CCK/W33 120 200 62 510 695 7.75
24124 CC/W33 120 200 80 655 950 10.3
24124 CCK30/W33 120 200 80 655 950 10
24124-2CS2/VT143 120 200 80 655 950 10.5
FAQ:

Q1: What is the delivery time if I place an order?
A: We have 330 pieces of the 22218CC/W33 roller bearing available in stock. For orders of up to 330 pieces, we can deliver within 2-3 days after payment is received. If you quantity is more than 330 pieces, delivery will take approximately 10-20 days.

Q2: Do your bearings come with a warranty?
A: Yes, our 22218 CC/W33 spherical roller bearings include a 1-year warranty.

Q3: What are my shipping options?
A: We provide multiple shipping options, including express services such as DHL, UPS, and FedEx, as well as air or sea freight. The best method will depend on your order’s total weight and your shipping budget.

Shipping & Payment Terms
Shipping Method:

1. Sea shipping for mass cargos (GW > 500KGS)

2. Air shipping (GW between 100KGS – 500 KGS)

3. Express, such as DHL, TNT, Fedex, UPS for small cargos ( GW < 100KGS)

4. If you have shipping agent in China, we can send goods to your shipping agent's warehouse

shipping

Payment Terms:

We accept T/T, W/U, PAYPAL, L/C etc

Payment Terms
