Bore(d): 35mm/ 1.378 inch
Outer Diameter (D): 80mm/ 3.1496 inch
Width (B): 48mm/ 1.8898 inch
Mass: 0.72kg/ 1.587lb
Type: ball bearing
Material: 440 stainless steel
Enclosure: double sealed
Certificate: ISO9001: 2015
Lubrication Feature: non-relubricatable
SUC307 Bearing Bore(d): 35mm/ 1.378 inch
Outer Diameter (D): 80mm/ 3.1496 inch
Width (B): 48mm/ 1.8898 inch
Mass: 0.72kg/ 1.587lb
Type: ball bearing
Material: 440 stainless steel
Bore Shape: cylindrical bore
Locking Style: set screw locking
Enclosure: double sealed
Certificate: ISO9001: 2015
Lubrication Feature: non-relubricatable
Operating Temperature: -20 °C to 100 °C
| Bearing Model | Shaft Dia | D | Bi | Be | n | m | G | ds | Mass |
| mm | (kg) | ||||||||
| SUC305 | 25 | 62 | 38 | 20 | 15 | 23 | 6 | M6×1.0 | 0.35 |
| SUC306 | 30 | 72 | 43 | 23 | 17 | 26 | 6 | M8×1.0 | 0.56 |
| SUC307 | 35 | 80 | 48 | 25 | 19 | 29 | 8 | M8×1.0 | 0.72 |
| SUC308 | 40 | 90 | 52 | 27 | 19 | 33 | 10 | M10×1.25 | 1.00 |
| SUC309 | 45 | 100 | 57 | 29 | 22 | 35 | 10 | M10×1.25 | 1.36 |
| SUC310 | 50 | 110 | 61 | 32 | 22 | 39 | 12 | M12×1.50 | 1.65 |
| SUC311 | 55 | 120 | 66 | 34 | 25 | 41 | 12 | M12×1.50 | 2.08 |
| SUC312 | 60 | 130 | 71 | 36 | 26 | 45 | 12 | M12×1.50 | 2.60 |
| SUC313 | 65 | 140 | 75 | 38 | 30 | 45 | 12 | M12×1.50 | 3.24 |
| SUC314 | 70 | 150 | 78 | 40 | 33 | 45 | 12 | M12×1.50 | 3.91 |
| SUC315 | 75 | 160 | 82 | 42 | 32 | 50 | 14 | M14×1.50 | 4.70 |
| SUC316 | 80 | 170 | 86 | 44 | 34 | 52 | 16 | M16×1.50 | 5.06 |
| SUC317 | 85 | 180 | 96 | 46 | 40 | 56 | 16 | M16×1.50 | 6.90 |
| SUC318 | 90 | 190 | 96 | 48 | 40 | 56 | 16 | M16×1.50 | 8.03 |
| SUC319 | 95 | 200 | 103 | 50 | 41 | 62 | 16 | M16×1.50 | 8.91 |
| SUC320 | 100 | 215 | 108 | 54 | 42 | 66 | 18 | M18×1.50 | 11.20 |
1. Send us your inquiry with the bearing model numbers and required quantities.
2. We will provide you with a detailed price quotation.
3. If you need a freight quote, please share your full delivery address so we can calculate the shipping cost.
4. Once you confirm the prices, we will issue an invoice for payment.
5. After we receive your payment, we will process your order and arrange shipment.
1. Sea shipping for mass cargos (GW > 500KGS)
2. Air shipping (GW between 100KGS – 500 KGS)
3. Express, such as DHL, TNT, Fedex, UPS for small cargos ( GW < 100KGS)
4. If you have shipping agent in China, we can send goods to your shipping agent's warehouse
We accept T/T, W/U, PAYPAL, L/C etc
