SUC209 Bearing For Housing YAR209-2RF/HV 45mm Bore
Inner Diameter: 45mm
Outer Diameter: 85mm
Width of Inner Ring: 49.2mm
Mass: 0.67kg
Material: 440c stainless steel
Set Screw Size: M8x1
Precision: standard precision ABEC1
Operating Temperature: -20 °C to 100 °C
SUC209 Bearing Datasheet:
SUC209 bearing is a stainless steel insert bearing. With respect to this model,
Inner Diameter: 45mm
Outer Diameter: 85mm
Width of Inner Ring: 49.2mm
Mass: 0.67kg
Material: stainless steel 440
Set Screw Size: M8x1
Seal Type: 2 seals on both sides
Lubrication: standard lubrication
Precision: standard precision ABEC1
Operating Temperature: -20 °C to 100 °C
Replacement: SUC209, YAR209-2RF/HV, YAR 209-2RF/HV
Bearing Applications:
The SUC209 stainless steel insert bearing is versatile and can be used in many light to medium-duty applications. Frequent applications include:
Agricultural Equipment – e.g., small tractors, harvesters, seeders
Conveyor Systems – rollers and shafts in packaging or material handling
HVAC Systems – fan shafts, blowers, and air handling units
Electric Motors – small motors in appliances or machinery
Food Processing Equipment – mixers, conveyors, and packaging machines (stainless steel helps with corrosion resistance)
General Machinery – any application requiring resistance to corrosion, moderate loads, and compact bearing design
Explore Our Selection of Stainless Steel Insert Ball Bearings:
| Bearing Number | d | D | Bi | Be | Weight |
| (kg) | |||||
| SUC202 | 15 | 40 | 27.4 | 14 | 0.14 |
| SUC203 | 17 | 40 | 27.4 | 14 | 0.13 |
| SUC204 | 20 | 47 | 31 | 17 | 0.15 |
| SUC205 | 25 | 52 | 34.1 | 17 | 0.22 |
| SUC206 | 30 | 62 | 38.1 | 19 | 0.34 |
| SUC207 | 35 | 72 | 42.9 | 20 | 0.52 |
| SUC208 | 40 | 80 | 49.2 | 21 | 0.68 |
| SUC209 | 45 | 85 | 49.2 | 22 | 0.78 |
| SUC210 | 50 | 90 | 51.6 | 22 | 0.85 |
| SUC211 | 55 | 100 | 55.6 | 25 | 1.22 |
| SUC212 | 60 | 110 | 65.1 | 27 | 1.65 |
| SUC213 | 65 | 120 | 65.1 | 29 | 1.96 |
| SUC214 | 70 | 125 | 74.6 | 30 | 2.06 |
| SUC215 | 75 | 130 | 77.8 | 30 | 2.3 |
| SUC216 | 80 | 140 | 82.6 | 33 | 2.79 |
| SUC217 | 85 | 150 | 85.7 | 35 | 3.59 |
| SUC218 | 90 | 160 | 96 | 37 | 4.45 |
| SUC220 | 100 | 180 | 108 | 41 | 4.56 |
Questions that help when SUC209 and YAR209-2RF/HV is on the shortlist
When is SUC209 and YAR209-2RF/HV worth comparing against nearby pillow block bearings options?
Comparison helps when dimensional fit is only part of the decision and load direction, sealing, clearance, speed, temperature, or repeat-order stability still need to be confirmed. Reviewing one or two nearby options early usually reduces sourcing mistakes later.
What details usually matter before approving SUC209 and YAR209-2RF/HV for repeat supply?
Buyers normally confirm the part reference, main dimensions, application, speed range, operating environment, sealing needs, and any packaging or marking requirements. That gives the supplier a cleaner basis for confirming availability and suitable alternatives.
Which next step usually helps after SUC209 and YAR209-2RF/HV is shortlisted?
A quick review of Pillow Block Bearings, one more commercial destination, and one practical guide usually saves time. That combination helps separate simple replacement orders from jobs that still need fit or application review.
Why keep a supporting guide linked beside SUC209 and YAR209-2RF/HV?
Because it makes later decisions faster. When sizing notes, application cues, and nearby options stay close to the product, engineering, purchasing, and maintenance teams can revisit the same logic without starting the review from zero.
Shipping Method:
1. Sea shipping for mass cargos (GW > 500KGS)
2. Air shipping (GW between 100KGS – 500 KGS)
3. Express, such as DHL, TNT, Fedex, UPS for small cargos ( GW < 100KGS)
4. If you have shipping agent in China, we can send goods to your shipping agent's warehouse
Payment Terms:
We accept T/T, W/U, PAYPAL, L/C etc
Buyer FAQ
Questions buyers ask before choosing the next bearing option
What should I confirm before ordering SUC209 Bearing For Housing YAR209-2RF/HV 45mm Bore?
Confirm the bearing number, bore size, outside diameter, width, seal or shield type, cage material, clearance, precision level, quantity, and application. These details help prevent a size match from becoming a performance mismatch.
Can this bearing be matched for replacement or repeat supply?
Yes. Replacement and repeat orders are easier when the original marking, measured dimensions, photos, application, and quantity are available. If the marking is unclear, the team can start from the size and working condition.
Which product family does this bearing belong to?
This item is handled within the Pillow Block Bearings family. Comparing the family page can help buyers review similar sizes, seal options, load direction, and related bearing choices before requesting a quote.
What affects price and lead time for this bearing?
Price and lead time can change with quantity, stock availability, precision grade, clearance, material, cage, seal or shield type, lubrication, packaging, and whether the order needs standard matching or custom production.
How is this bearing checked before delivery?
Inspection can include material review, dimensional measurement, noise and vibration checks, surface and crack checks, visual review, and packaging inspection according to the confirmed order requirements.
