RLS36 Bearing LJ 4 1/2 Imperial Radial Ball Bearing LS 22
Inner Diameter: 114.300mm/ 4.5 inch
Outer Diameter: 203.200mm/ 8 inch
Width: 33.338mm/ 1.3125 inch
Mass: 4.00kg/ 8.836 lb
Sheilds: without
Number of Row: single row
Structure: deep groove ball bearing
RLS36 Bearing Specification:
RLS36 bearing is an imperial deep groove ball bearing.
Inner Diameter: 114.300mm/ 4.5 inch
Outer Diameter: 203.200mm/ 8 inch
Width: 33.338mm/ 1.3125 inch
Mass: 4.00kg/ 8.836 lb
Sheilds: without
Number of Row: single row
Structure: deep groove ball bearing
Relubrication Feature: without
Certificate: ISO9001: 2015
Warranty: 1 year
Precision: ABEC1, P0
Material: bearing steel
Cage: steel
Radial Internal Play: standard CN
Replacements: RLS 36, RLS-36, LJ-4 1/2 E, LJ 4 1/2, LJ4 1/2, LJ4.1/2, LS 22, LS22, LS22AC
Key Features:
1. Single Row Design: The RLS36 bearing is a single row deep groove ball bearing, specifically engineered to handle both high radial forces and axial forces in one direction. This design makes it ideal for applications requiring precise load management and stability under combined loads.
2. Solid Inner and Outer Rings: The bearing LJ-4 1/2 E features robust inner and outer rings, providing structural integrity and long-term durability. These solid rings help maintain consistent performance even under demanding operating conditions, ensuring reliability in critical applications.
3. Efficient Load Support: Thanks to its advanced design, the LS22 bearing is capable of supporting substantial radial and axial loads. Its ability to manage forces effectively makes it versatile for use in various industries, including automotive, machinery, and industrial equipment.
RLS Bearing Compatibility and Cross-Reference Guide:
| RLS 4 | LS 5 | LJ 1/2 | RLS 4 |
| RLS 5 | LS 7 | LJ 5/8 | RLS 5 |
| RLS 6 | LS 8 | LJ 3/4 | RLS 6 |
| RLS 7 | LS 9 | LJ 7/8 | RLS 7 |
| RLS 8 | LS 10 | LJ 1 E | RLS 8 |
| RLS 9 | LS 11 | LJ 1 1/8 | RLS 9 |
| RLS 10 | LS 12 | LJ 1 1/4 | RLS 10 |
| RLS 11 | LS 12 1/2 | LJ 1 3/8 | RLS 11 |
| RLS 12 | LS 13 | LJ 1 1/2 | RLS 12 |
| RLS 13 | LS 13 1/2 | LJ 1 5/8 | RLS 13 |
| RLS 14 | LS 14 | LJ 1 3/4 | RLS 14 |
| RLS 15 | LS 14 1/2 | LJ 1 7/8 | RLS 15 |
| RLS 16 | LS 15 | LJ 2 E | RLS 16 |
| RLS 18 | LS 16 | LJ 2 1/4 | RLS 18 |
| RLS 20 | LS 17 | LJ 2 1/2 | RLS 20 |
| RLS 22 | LS 18 | LJ 2 3/4 | RLS 22 |
| RLS 24 | LS 19 | LJ 3 E | RLS 24 |
| RLS 26 | LS 19 1/2 | LJ 3 1/4 | RLS 26 |
| RLS 28 | LS 20 | LJ 3 1/2 | RLS 28 |
| RLS 30 | LS 20 1/2 | LJ 3 3/4 | RLS 30 |
| RLS 32 | LS 21 | LJ 4 E | RLS 32 |
| RLS 34 | LS 21 1/2 | LJ 4 1/4 | RLS 34 |
| RLS 36 | LS 22 | LJ 4 1/2 | RLS 36 |
| RLS 38 | LS 22 1/2 | LJ 4 3/4 | RLS 38 |
| RLS 40 | LS 23 | LJ 5 E | RLS 40 |
Questions that usually come up before ordering RLS36
When is RLS36 worth comparing against nearby deep groove ball bearings options?
Comparison helps when dimensional fit is only part of the decision and load direction, sealing, clearance, speed, temperature, or repeat-order stability still need to be confirmed. Reviewing one or two nearby options early usually reduces sourcing mistakes later.
What details usually matter before approving RLS36 for repeat supply?
Buyers normally confirm the part reference, main dimensions, application, speed range, operating environment, sealing needs, and any packaging or marking requirements. That gives the supplier a cleaner basis for confirming availability and suitable alternatives.
Which next step usually helps after RLS36 is shortlisted?
A quick review of Deep Groove Ball Bearings, one more commercial destination, and one practical guide usually saves time. That combination helps separate simple replacement orders from jobs that still need fit or application review.
Why keep a supporting guide linked beside RLS36?
Because it makes later decisions faster. When sizing notes, application cues, and nearby options stay close to the product, engineering, purchasing, and maintenance teams can revisit the same logic without starting the review from zero.
Shipping Method:
1. Sea shipping for mass cargos (GW > 500KGS)
2. Air shipping (GW between 100KGS – 500 KGS)
3. Express, such as DHL, TNT, Fedex, UPS for small cargos ( GW < 100KGS)
4. If you have shipping agent in China, we can send goods to your shipping agent's warehouse
Payment Terms:
We accept T/T, W/U, PAYPAL, L/C etc
Buyer FAQ
Questions buyers ask before choosing the next bearing option
What should I confirm before ordering RLS36 Bearing LJ 4 1/2 Imperial Radial Ball Bearing LS 22?
Confirm the bearing number, bore size, outside diameter, width, seal or shield type, cage material, clearance, precision level, quantity, and application. These details help prevent a size match from becoming a performance mismatch.
Can this bearing be matched for replacement or repeat supply?
Yes. Replacement and repeat orders are easier when the original marking, measured dimensions, photos, application, and quantity are available. If the marking is unclear, the team can start from the size and working condition.
Which product family does this bearing belong to?
This item is handled within the Deep Groove Ball Bearings family. Comparing the family page can help buyers review similar sizes, seal options, load direction, and related bearing choices before requesting a quote.
What affects price and lead time for this bearing?
Price and lead time can change with quantity, stock availability, precision grade, clearance, material, cage, seal or shield type, lubrication, packaging, and whether the order needs standard matching or custom production.
How is this bearing checked before delivery?
Inspection can include material review, dimensional measurement, noise and vibration checks, surface and crack checks, visual review, and packaging inspection according to the confirmed order requirements.
Need help checking fit, price, or lead time? Request a bearing quote
