HM218248/HM218210 Bearing HM218248-HM218210 Taper Roller Bearing SET414
d: 89.975mm/ 3.5423 in
D: 146.975mm/ 5.7864 in
T: 40mm/ 1.5748 in
Mass: 2.55kg/ 5.622lbs
Cone Number: HM218248
Cup Number: HM218210
Material: chrome steel
Warranty: 1 year
HM218248/HM218210 Bearing Parameters:
HM218248/HM218210 bearing is a complete set, including both the cone and cup.
The bearing specifications are as follows:
| d: | 89.975mm/ 3.5423 in |
| D: | 146.975mm/ 5.7864 in |
| T: | 40mm/ 1.5748 in |
| Mass: | 2.55kg/ 5.622lbs |
| Cone Number: | HM218248 |
| Cup Number: | HM218210 |
| Material: | chrome steel |
| Cage Material: | steel |
| Category: | taper roller bearing |
| Number or Row: | single row |
| Precision: | ABEC1, P0 |
| Seal Type: | open type |
| Equivalents: | HM218248-HM218210 |
| HM218248 – HM218210 | |
| HM218248/10 | |
| HM218248-9X021 | |
| HM218248/210 | |
| SET414 | |
| SET 414 | |
| set 414 | |
| 4T-HM218248/HM218210 |
Key Features:
1. Single-Row Tapered Design:
HM218248/210 bearing utilizes tapered rollers and conical raceways, allowing for efficient handling of combined loads.
2. High Load Capacity:
HM218248 – HM218210 supports substantial radial and axial loads in one direction, with axial capacity increasing as the contact angle increases.
3. Versatile Mounting Options:
HM218248-HM218210 bearing can be used in mirror-image pairs and arranged in X, O, or tandem configurations to accommodate various application requirements.
4. Easy Assembly and Disassembly:
Consists of a separable cup (outer ring) and cone (inner ring with cage and rollers), simplifying installation and maintenance.
5. Open Construction:
The open design facilitates cooling and lubrication, enhancing bearing life and performance.
SET Numbers with Components Breakdown:
| SET Number | SET COMPONENTS |
| SET 64 | HM903249/HM903210 |
| SET65 | M86647/M86610 |
| SET67 | HM88649H/HM88610 |
| SET69 | LM501349/LM501314 |
| SET70 | LM29749/LM29710 |
| SET78 | 55200C/55437 |
| SET81 | HM88542/HM88510 |
| SET82 | LM104949/JLM104910 |
| SET96 | 25877A/25821 |
| SET100 | HM89446/HM89410 |
| SET104 | L44642/L44610 |
| SET107 | JLM104948/JLM104910 |
| SET118 | JLM506849/JLM506810 |
| SET219 | M88046/M88010 |
| SET222 | HM88649HP/HM88610P |
| SET242 | M88043/M88010 |
| SET268 | LM29749/LM29711 |
| SET280 | U298/K529698 |
| SET284 | U298/K525376 |
| SET308 | M84548/M84510 |
| SET309 | M86649/M86610 |
| SET312 | HM89449/HM89410 |
| SET328 | M802048/M802011 |
| SET401 | 580/572 |
| SET402 | 582/572 |
| SET403 | 594A/592A |
| SET404 | 598A/592A |
| SET405 | 663/653 |
| SET406 | 3782/3720 |
| SET407 | 28622/28682 |
| SET408 | 39590/39520 |
| SET409 | 45220/45280 |
| SET410 | 45220/45284 |
| SET411 | 47686/47620 |
| SET412 | HM212047/HM212011 |
| SET413 | HM212049/HM212011 |
| SET414 | HM218248/HM218210 |
| SET415 | HM518445/HM518410 |
| SET416 | 45220/45291 |
| SET417 | 47820/47890 |
| SET418 | H715311/H715334 |
| SET419 | H715311/H715343 |
| SET420 | H715311/H715345 |
| SET421 | HM516410/HM516449A |
| SET422 | HM516410/HM516449C |
| SET423 | 6420/6461A |
| SET424 | 552A/555S |
| SET425 | 563/567 |
| SET426 | 47620/47679 |
Installation Tips for HM218248/HM218210 Bearing:
1. Clean all components thoroughly before installation.
2. Ensure the bearing and housing are free from dirt and debris.
3. Apply a thin layer of appropriate lubricant to the bearing surfaces.
4. Press the cone and cup evenly to avoid misalignment or damage.
5. Do not use excessive force; use proper tools for installation.
6. After assembly, check for smooth rotation and correct preload or clearance.
Questions that usually come up before ordering HM218248/HM218210 and HM218248-HM218210
When is HM218248/HM218210 and HM218248-HM218210 worth comparing against nearby taper roller bearings options?
Comparison helps when dimensional fit is only part of the decision and load direction, sealing, clearance, speed, temperature, or repeat-order stability still need to be confirmed. Reviewing one or two nearby options early usually reduces sourcing mistakes later.
What details usually matter before approving HM218248/HM218210 and HM218248-HM218210 for repeat supply?
Buyers normally confirm the part reference, main dimensions, application, speed range, operating environment, sealing needs, and any packaging or marking requirements. That gives the supplier a cleaner basis for confirming availability and suitable alternatives.
Which next step usually helps after HM218248/HM218210 and HM218248-HM218210 is shortlisted?
A quick review of Taper Roller Bearings, one more commercial destination, and one practical guide usually saves time. That combination helps separate simple replacement orders from jobs that still need fit or application review.
Why keep a supporting guide linked beside HM218248/HM218210 and HM218248-HM218210?
Because it makes later decisions faster. When sizing notes, application cues, and nearby options stay close to the product, engineering, purchasing, and maintenance teams can revisit the same logic without starting the review from zero.
Shipping Method:
1. Sea shipping for mass cargos (GW > 500KGS)
2. Air shipping (GW between 100KGS – 500 KGS)
3. Express, such as DHL, TNT, Fedex, UPS for small cargos ( GW < 100KGS)
4. If you have shipping agent in China, we can send goods to your shipping agent's warehouse
Payment Terms:
We accept T/T, W/U, PAYPAL, L/C etc
Buyer FAQ
Questions buyers ask before choosing the next bearing option
What should I confirm before ordering HM218248/HM218210 Bearing HM218248-HM218210 Taper Roller Bearing SET414?
Confirm the bearing number, bore size, outside diameter, width, seal or shield type, cage material, clearance, precision level, quantity, and application. These details help prevent a size match from becoming a performance mismatch.
Can this bearing be matched for replacement or repeat supply?
Yes. Replacement and repeat orders are easier when the original marking, measured dimensions, photos, application, and quantity are available. If the marking is unclear, the team can start from the size and working condition.
Which product family does this bearing belong to?
This item is handled within the Taper Roller Bearings family. Comparing the family page can help buyers review similar sizes, seal options, load direction, and related bearing choices before requesting a quote.
What affects price and lead time for this bearing?
Price and lead time can change with quantity, stock availability, precision grade, clearance, material, cage, seal or shield type, lubrication, packaging, and whether the order needs standard matching or custom production.
How is this bearing checked before delivery?
Inspection can include material review, dimensional measurement, noise and vibration checks, surface and crack checks, visual review, and packaging inspection according to the confirmed order requirements.
