FYJ 90 TF Bearing FYJ90TF Flanged Bearing Unit

Bore: 90mm
Outer Diameter: 235mm
Bearing Width: 89mm
Mass: 10.80kg
Bore Type: cylindrical
Housing Material: cast iron
Insert Ball Bearing Material: bearing steel

FYJ 90 TF Bearing Specification:

FYJ 90 TF Bearing Bore: 90mm
Outer Diameter: 235mm
Bearing Width: 89mm
Mass: 10.80kg
Bore Type: cylindrical
Housing Material: cast iron
Insert Ball Bearing Material: bearing steel
Number of Fixing Holes: 4
Bearing Type: square flange type
Lubrication: grease

Key Features:

Four-bolt square flange design: FYJ90TF provides stable mounting and firm support, making installation simple and secure.
Suitable for 90 mm shaft diameter: Designed to accommodate a 90 mm shaft, suitable for medium to heavy-duty machinery applications.
Self-aligning capability: The bearing insert can compensate for minor shaft misalignment, helping to reduce stress and extend service life.
Reliable sealing structure: Equipped with effective seals to help protect the bearing from dust, dirt, and other contaminants.
Pre-lubricated bearing insert: Usually supplied with grease lubrication, reducing maintenance requirements after installation.
Strong housing construction: The flanged housing provides good rigidity and durability for stable operation.
