Bearing Cone: 419
Bearing Cup: 414
d (Bore): 1-5/8 inch/ 41.275 mm
D (Outer Diameter): 3.4843 inch/ 88.501 mm
B (Cone Width): 1.1450 inch/ 29.083 mm
T (Total Width): 1.0625 inch/ 26.988 mm
Mass: 0.766kg/ 1.689lb
Cage: steel
419/414 Bearing Cone: 419
Bearing Cup: 414
d (Bore): 1-5/8 inch/ 41.275 mm
D (Outer Diameter): 3.4843 inch/ 88.501 mm
B (Cone Width): 1.1450 inch/ 29.083 mm
T (Total Width): 1.0625 inch/ 26.988 mm
Mass: 0.766kg/ 1.689lb
Cage: steel
Material: bearing steel
Number of Row: single
Category: taper roller bearing
Precision: standard ABEC1, P0
Lubrication: grease or oil
Working Temperature: –30 °C to +120 °C
Interchange Numbers: 419 / 414, 419-414, 419-99401, 414/419, 414-419
| Model Number | Dimensions (dxDxB)/ mm | Mass (kg) |
| 32310/32355 | 55×110×42.25 | 1.709 |
| 33225/33472 | 57.15×120×29.29.794 | 1.637 |
| 33262/33462 | 66.675×117.475×30.163 | 1.32 |
| 33275/33462 | 69.85×117.475×30.163 | 1.24 |
| 33275/33472 | 69.85×120×29.794 | 1.32 |
| 33281/33462 | 71.438×117.475×30.163 | 1.2 |
| 33281/33472 | 71.438×120×29.794 | 1.2 |
| 33885/33821 | 44.45×95.25×27.783 | 0.96 |
| 33889/33821 | 50.8×95.25×27.783 | 0.85 |
| 33891/33821 | 52.388×95.25×27.783 | 0.816 |
| 33895/33822 | 53.975×95.25×27.738 | 0.819 |
| 36691/36620 | 146.05×193.675×28.575 | 2.23 |
| 36690/36626 | 146.05×203.2×28.575 | 2.8 |
| 36690/36920 | 177.8×227.012×30.165 | 6.611 |
| 37425/37625 | 107.95×158.75×23.02 | 1.35 |
| 39578/39520 | 53.975×112.712×30.162 | 1.44 |
| 39585/39520 | 63.5×112.713×30.163 | 1.236 |
| 39590/39520 | 66.675×112.71×30.163 | 1.159 |
| 418/414 | 38.1×88.5×26.988 | 0.327 |
| 419/414 | 41.275×88.5×26.988 | 0.78 |
| 438/432 | 44.45×95.25×27.783 | 0.996 |
| 444/432 | 38.1×95.25×27.783 | 1.03 |
| 455/453X | 50.8×104.775×30.162 | 1.18 |
| 455S/453X | 50.8×104.775×30.162 | 1.16 |
| 455/453 | 50.8×107.59×27.783 | 1.23 |
