Bore: 1 in/ 25.40 mm
Outer Diameter: 2.4409 in/ 61.999 mm
Total Diameter: 0.75 in/ 19.05 mm
Mass: 0.661lb/ 0.30kg
Cone Number: 15101
Cup Number: 15245
Category: taper roller bearing
Precision: standard precision, ABEC1
15101/15245 Bearing Bore: 1 in/ 25.40 mm
Outer Diameter: 2.4409 in/ 61.999 mm
Total Diameter: 0.75 in/ 19.05 mm
Mass: 0.661lb/ 0.30kg
Cone Number: 15101
Cup Number: 15245
Number of Row: single row
Category: tapered roller bearing
Precision: standard precision, ABEC1
Warranty: 1 year
Certificate: ISO9001:2015
Cage Material: stamped steel
Equivalents: 15101 / 15245, 15245/15101, 15101-15245, 15101 – 15245, 15101/245, Set73, Set 73, SET 73, set-73, 15101-99401
1. Support combined loads: The 15101/15245 bearing manages both radial and axial forces at the same time, making it suitable for demanding applications.
2. Carry heavy loads: With its tapered design and larger contact angle, the bearing 15101-15245 handles higher axial loads without losing stability.
3. Fit multiple arrangements: Users can install it in X, O, or tandem configurations to match different engineering needs.
4. Simplify installation and removal: The separate cup and cone design lets you assemble or disassemble the set73 bearing quickly and with less effort.
5. Deliver reliable performance: The tapered raceways and roller set provide consistent operation even under heavy stress.
| SET Number | CUP & CONE COMPONENTS |
| SET14 | L44643/L44610 |
| SET15 | 07100/07196 |
| SET16 | LM12749/LM12711 |
| SET18 | LM102949/LM102911 |
| SET20 | U399A/K518783/K523967 |
| SET73 | 15101/15245 |
| SET268 | LM29749/LM29711 |
| SET280 | U298/K529698 |
| SET284 | U298/K525376 |
| SET308 | M84548/M84510 |
| SET309 | M86649/M86610 |
| SET312 | HM89449/HM89410 |
| SET328 | M802048/M802011 |
| SET401 | 580/572 |
| SET402 | 582/572 |
| SET403 | 594A/592A |
| SET404 | 598A/592A |
| SET405 | 663/653 |
| SET406 | 3782/3720 |
| SET407 | 28622/28682 |
| SET408 | 39590/39520 |
| SET409 | 45220/45280 |
| SET410 | 45220/45284 |
| SET411 | 47686/47620 |
| SET412 | HM212047/HM212011 |
| SET413 | HM212049/HM212011 |
| SET414 | HM218248/HM218210 |
| SET415 | HM518445/HM518410 |
| SET416 | 45291/45220 |
| SET417 | 47890/47820 |
| SET418 | H715311/H715334 |
| SET419 | H715311/H715343 |
| SET420 | H715311/H715345 |
| SET421 | HM516410/HM516449A |
| SET422 | HM516410/HM516449C |
| SET423 | 6420/6461A |
| SET424 | 552A/555S |
| SET425 | 563/567 |
| SET426 | 47620/47679 |
Comparison helps when dimensional fit is only part of the decision and load direction, sealing, clearance, speed, temperature, or repeat-order stability still need to be confirmed. Reviewing one or two nearby options early usually reduces sourcing mistakes later.
Buyers normally confirm the part reference, main dimensions, application, speed range, operating environment, sealing needs, and any packaging or marking requirements. That gives the supplier a cleaner basis for confirming availability and suitable alternatives.
A quick review of Taper Roller Bearings, one more commercial destination, and one practical guide usually saves time. That combination helps separate simple replacement orders from jobs that still need fit or application review.
Because it makes later decisions faster. When sizing notes, application cues, and nearby options stay close to the product, engineering, purchasing, and maintenance teams can revisit the same logic without starting the review from zero.
1. Sea shipping for mass cargos (GW > 500KGS)
2. Air shipping (GW between 100KGS – 500 KGS)
3. Express, such as DHL, TNT, Fedex, UPS for small cargos ( GW < 100KGS)
4. If you have shipping agent in China, we can send goods to your shipping agent's warehouse
We accept T/T, W/U, PAYPAL, L/C etc
Buyer FAQ
Confirm the bearing number, bore size, outside diameter, width, seal or shield type, cage material, clearance, precision level, quantity, and application. These details help prevent a size match from becoming a performance mismatch.
Yes. Replacement and repeat orders are easier when the original marking, measured dimensions, photos, application, and quantity are available. If the marking is unclear, the team can start from the size and working condition.
This item is handled within the Taper Roller Bearings family. Comparing the family page can help buyers review similar sizes, seal options, load direction, and related bearing choices before requesting a quote.
Price and lead time can change with quantity, stock availability, precision grade, clearance, material, cage, seal or shield type, lubrication, packaging, and whether the order needs standard matching or custom production.
Inspection can include material review, dimensional measurement, noise and vibration checks, surface and crack checks, visual review, and packaging inspection according to the confirmed order requirements.
