LM125748-LM125711 Bearing LM125748/11 Taper Roller Bearing
Bearing Cone: LM125748
Bearing Cup: LM125711
Bore (d): 127mm (5 inch)
Outer Diameter (D): 174.625mm (6.875 inch)
Cone Width (B): 36.513mm (1.4375 inch)
Total Width (T): 36.513mm (1.4375 inch)
Mass: 2.54kg/ 5.60lb
LM125748-LM125711 Bearing Specification:
LM125748-LM125711 bearing features a tapered roller bearing.
Concerning this bearing model,
Bearing Cone: LM125748
Bearing Cup: LM125711
Bore (d): 127mm (5 inch)
Outer Diameter (D): 174.625mm (6.875 inch)
Cone Width (B): 36.513mm (1.4375 inch)
Total Width (T): 36.513mm (1.4375 inch)
Mass: 2.54kg/ 5.60lb
Cage: steel cage
Rollers & Rings Material: bearing steel
Lubrication: standard grease or oil
Precision: standard precision ABEC1, P0
Replacements: LM125748/LM125711, LM125748/711, LM125748 – LM125711
Imperial Taper Roller Bearings We Offer:
| Bearing Model | Dimensions(mm) | Mass (kg) |
| 387/383X | 57.150×100.000×25.400 | 0.760 |
| 45289/45220 | 57.150×104.775×30.162 | 1.080 |
| 45289/45221 | 57.150×104.775×30.162 | 1.090 |
| 45290/45220 | 57.150×104.775×30.162 | 1.080 |
| 45290/45221 | 57.150×104.775×30.162 | 1.090 |
| 45291/45220 | 57.150×104.775×30.162 | 1.050 |
| 45291/45221 | 57.150×104.775×30.162 | 1.060 |
| 462/453X | 57.150×104.775×30.162 | 1.050 |
| 462A/453X | 57.150×104.775×30.162 | 1.040 |
| 469/453X | 57.150×104.775×30.162 | 1.040 |
| 462/453A | 57.150×107.950×27.783 | 1.100 |
| 462/453AS | 57.150×107.950×27.783 | 1.100 |
| 469/453A | 57.150×107.950×27.783 | 1.100 |
| 462/452A | 57.150×107.950×32.558 | 1.210 |
| 390/394A | 57.150×110.000×22.000 | 0.940 |
| 390/394AS | 57.150×110.000×22.000 | 0.920 |
| 462/454 | 57.150×110.000×27.795 | 1.230 |
| 29665/29620 | 57.150×112.712×25.400 | 1.210 |
| 390/3920 | 57.150×112.712×26.967 | 1.120 |
| 3979/3920 | 57.150×112.712×30.162 | 1.370 |
| 39580/39520 | 57.150×112.712×30.162 | 1.380 |
| 39580/39521 | 57.150×117.712×30.162 | 1.380 |
| 39581/39520 | 57.150×112.712×30.162 | 1.340 |
| 66225/66462 | 57.150×117.475×33.338 | 1.500 |
| 623/612 | 57.150×120.650×41.275 | 2.100 |
| 623/612-S | 57.150×120.650×41.275 | 2.110 |
| 623A/612 | 57.150×120.650×41.275 | 2.070 |
| 66587/66520 | 57.150×122.238×33.338 | 1.690 |
| 72225C/72487 | 57.150×123.825×36.512 | 1.980 |
| 555-S/552 | 57.150×123.825×38.100 | 2.200 |
FAQ:
Q1: What applications suit this bearing?
A1: It can be used in gearboxes, transmissions, axles, heavy machinery, and other shafts requiring combined radial and axial support.
Q2: What loads can it handle?
A2: It handles heavy radial loads and axial (thrust) loads in one direction; axial capacity rises with larger contact angles.
Q3: Is the bearing separable?
A3: Yes. The cone (inner ring, rollers, cage) separates from the cup (outer ring) for easier mounting and maintenance.
Q4: What materials are used?
A4: Rollers and rings use hardened bearing steel; the cage is typically steel.
Questions that help when LM125748-LM125711 and LM125748/11 is on the shortlist
When is LM125748-LM125711 and LM125748/11 worth comparing against nearby taper roller bearings options?
Comparison helps when dimensional fit is only part of the decision and load direction, sealing, clearance, speed, temperature, or repeat-order stability still need to be confirmed. Reviewing one or two nearby options early usually reduces sourcing mistakes later.
What details usually matter before approving LM125748-LM125711 and LM125748/11 for repeat supply?
Buyers normally confirm the part reference, main dimensions, application, speed range, operating environment, sealing needs, and any packaging or marking requirements. That gives the supplier a cleaner basis for confirming availability and suitable alternatives.
Which next step usually helps after LM125748-LM125711 and LM125748/11 is shortlisted?
A quick review of Taper Roller Bearings, one more commercial destination, and one practical guide usually saves time. That combination helps separate simple replacement orders from jobs that still need fit or application review.
Why keep a supporting guide linked beside LM125748-LM125711 and LM125748/11?
Because it makes later decisions faster. When sizing notes, application cues, and nearby options stay close to the product, engineering, purchasing, and maintenance teams can revisit the same logic without starting the review from zero.
