Bore (d): 3-1/4 inch/ 82.55mm
Outer Diameter (D): 5.5115 inch/ 139.992mm
Cone Width (B): 1.4212 inch/ 36.098mm
Mass: 2.10kg/ 4.629lb
Cone Number: 582
Cup Number: 572
Equivalents: 582 – 572, 582/572, SET 402, Set402, set 402
582-572 Bearing Bore (d): 3-1/4 inch/ 82.55mm
Outer Diameter (D): 5.5115 inch/ 139.992mm
Cone Width (B): 1.4212 inch/ 36.098mm
Mass: 2.10kg/ 4.629lb
Cone Number: 582
Cup Number: 572
Seal: without
Cage: steel
Bearing Material: chrome steel
Number of Row: single row
Precision: standard ABEC1, P0
Working Temperature: –30 °C to +120 °C
Equivalents: 582 – 572, 582/572, SET 402, Set402, set 402
1. High Load Capacity: Designed to accommodate heavy radial and axial loads, making it suitable for demanding applications.
2. Durability: Constructed with high-quality materials to ensure long-lasting performance and resistance to wear and tear.
3. Precision Engineering: Manufactured to precise tolerances for excellent performance in high-speed and high-temperature environments.
4. Versatile Application: Suitable for a wide range of industrial applications, including automotive, machinery, and equipment.
5. Easy Installation and Maintenance: Designed for straightforward installation and maintenance, minimizing downtime and operational costs.
| Model Number | Size (Bore*OD*Bearing Width)/mm | Mass/kg |
| 580/572X | 82.550×139.700×36.512 | 2.110 |
| 582/572X | 82.550×139.700×36.512 | 2.070 |
| 580/572 | 82.550×139.992×36.512 | 2.140 |
| 580/574 | 82.550×139.992×36.512 | 2.140 |
| 582/572 | 82.550×139.992×36.512 | 2.100 |
| 47685/47621 | 82.550×139.992×36.512 | 2.130 |
| 47686/47621 | 82.550×139.992×36.512 | 2.120 |
| 580X/572 | 82.550×139.992×36.512 | 2.120 |
| HM617045/HM617010 | 82.550×142.138×42.862 | 2.770 |
| 663/653 | 82.550×146.050×41.275 | 2.730 |
| 663A/653 | 82.550×146.050×41.275 | 2.700 |
| 595/592XE | 82.550×147.638×35.717 | 2.590 |
| 595/592XS | 82.550×147.638×35.717 | 2.570 |
| 595/593X | 82.550×150.000×35.992 | 2.710 |
| 749A/742 | 82.550×150.089×44.450 | 3.350 |
| 750A/742 | 82.550×150.089×44.450 | 3.320 |
| 595/592AS | 82.550×152.400×35.717 | 2.820 |
| 595/592A | 82.550×152.400×39.688 | 2.990 |
| 663/652 | 82.550×152.400×41.275 | 3.100 |
| 757/752A | 82.550×159.995×47.625 | 4.260 |
| 757/752 | 82.550×161.925×47.625 | 4.390 |
| 6559C/6535 | 82.550×161.925×53.975 | 5.030 |
| 757/753 | 82.550×168.275×47.625 | 4.860 |
| 839/832 | 82.550×168.275×53.975 | 5.430 |
| 842/32 | 82.550×168.275×53.975 | 5.420 |
| H917849/H917810 | 82.550×180.975×53.975 | 6.220 |
| 27689/27620 | 83.345×125.412×25.400 | 1.050 |
| 27690/27620 | 83.345×125.412×25.400 | 1.030 |
| 27691/27620 | 83.345×125.412×25.400 | 1.000 |
Comparison helps when dimensional fit is only part of the decision and load direction, sealing, clearance, speed, temperature, or repeat-order stability still need to be confirmed. Reviewing one or two nearby options early usually reduces sourcing mistakes later.
Buyers normally confirm the part reference, main dimensions, application, speed range, operating environment, sealing needs, and any packaging or marking requirements. That gives the supplier a cleaner basis for confirming availability and suitable alternatives.
A quick review of Taper Roller Bearings, one more commercial destination, and one practical guide usually saves time. That combination helps separate simple replacement orders from jobs that still need fit or application review.
Because it makes later decisions faster. When sizing notes, application cues, and nearby options stay close to the product, engineering, purchasing, and maintenance teams can revisit the same logic without starting the review from zero.
1. Sea shipping for mass cargos (GW > 500KGS)
2. Air shipping (GW between 100KGS – 500 KGS)
3. Express, such as DHL, TNT, Fedex, UPS for small cargos ( GW < 100KGS)
4. If you have shipping agent in China, we can send goods to your shipping agent's warehouse
We accept T/T, W/U, PAYPAL, L/C etc
Buyer FAQ
Confirm the bearing number, bore size, outside diameter, width, seal or shield type, cage material, clearance, precision level, quantity, and application. These details help prevent a size match from becoming a performance mismatch.
Yes. Replacement and repeat orders are easier when the original marking, measured dimensions, photos, application, and quantity are available. If the marking is unclear, the team can start from the size and working condition.
This item is handled within the Taper Roller Bearings family. Comparing the family page can help buyers review similar sizes, seal options, load direction, and related bearing choices before requesting a quote.
Price and lead time can change with quantity, stock availability, precision grade, clearance, material, cage, seal or shield type, lubrication, packaging, and whether the order needs standard matching or custom production.
Inspection can include material review, dimensional measurement, noise and vibration checks, surface and crack checks, visual review, and packaging inspection according to the confirmed order requirements.
Need help checking fit, price, or lead time? Request a bearing quote
