2688 Bearing – Single Cone For Taper Roller Bearing

2688 Bearing Information:

Bore (d): 26.988 mm/ 1.0625 inch
Inner Ring Width (B): 25.433 mm/ 1.0013 inch
Mass: 0.26kg/ 0.57lb
Cage: press steel
Rings & Rollers: bearing steel
Hardness: 58-64 HRC
Seal Type: open
Tolerance: P0 / ABEC1
Relubrication Feature: without
Lubrication: standard grease or oil

FAQs:

Question 1: What is the matching cup for 2688 cone?
Answer: This bearing cone is typically used together with the 2631 cup.

Question 2: Can this bearing cone support both radial and axial loads?
Answer: Yes. As a tapered roller bearing cone, 2688 is designed to handle combined loads, including both radial loads and axial loads in one direction when paired with the correct bearing cup.

Question 3: Do you supply only the 2688 cone or the complete cone & cup set?
Answer: We may supply the 2688 tapered roller bearing cone separately or together with a matching cup, depending on your requirement. Please confirm whether you need only the cone or a complete tapered roller bearing set.
